MediaXtreme MediaZone

Keywest Technology MediaXtreme MediaZone System

MediaXtreme (MX) MediaZone is Keywest Technology's Digital Signage and Information
Channel product series. The series software and hardware is designed for easy content creation
and display with minimal graphics or video expertise. The device is capable of multi-zone and
layer compositing at the High-Definition output--the power to combine motion backgrounds,
multiple graphics pages, crawls, rolls, High-Definition MPEG1, 2, 4, WMV, AVI picture-in-
picture effects, stereo, 5.1, WAV and MP3 audio, transitions effects, logos, fades, and more.
Check www.mediaxtreme.tv for all the latest product specifications and features.
WARNING
**************************** *****************************
Lethal operating voltages present at system power supply unit—internal and external units. Completely
disconnect main power cord prior to opening cover or removing any panels. Only trained and authorized
personnel should attempt any internal modifications, repairs, or service.
***CAUTION***
Unit operates on 100 – 220 VAC 50 – 60 Hz Main Power. Inadequate power grounding can result in equipment
damage or destruction and could void warranty. Ensure you utilize provided power supply unit only. Use of
improper power supply can damage or destroy the unit and will void the warranty.
***CAUTION***
If the player is to be rack-mounted, do so using four heavy duty rack screws—rear support is recommended. Do not
use the MX as a shelf to support any weight other than its own. In any mounting configuration, ensure the unit is in
a clean, environmentally controlled location and ensure filters are cleaned regularly
Keywest Technology
2
th
14563 W. 96 Terrace
Lenexa, Kansas 66215
23 Mar 2009
800.331.2019
Change 06
www.keywesttechnology.com
