KeyWest Technology MXB-AV Manual

Mediaxtreme series, mediazone series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MediaXtreme
MediaZone

Table of Contents

Keywest Technology MediaXtreme MediaZone System ............................................................... 2
Models & Connections ................................................................................................................... 3
MX Player Setup............................................................................................................................. 7
Player Network Setup ..................................................................................................................... 7
Setup Player Properties (INI Files) ............................................................................................... 12
Set the MX to PLAY..................................................................................................................... 12
MediaZone Scheduler Software Installation................................................................................. 13
Minimum Editor System Recommendations ................................................................................ 13
Install Software ............................................................................................................................. 13
Software Registration & Seat Licenses......................................................................................... 14
MediaZone Scheduler Graphical User Interface (GUI)................................................................ 14
Browser ......................................................................................................................................... 19
Menu Bar ...................................................................................................................................... 19
Quick Controls .............................................................................................................................. 20
Zones Layers ................................................................................................................................. 20
Tutorial.......................................................................................................................................... 21
Zone Attributes ............................................................................................................................. 21
Create a New Set........................................................................................................................... 23
Background Zone.......................................................................................................................... 25
Add BMPs, JPGs, PNGs and Other Media to Zones.................................................................... 32
Add Crawls ................................................................................................................................... 37
Add Logos..................................................................................................................................... 40
Animated Logos............................................................................................................................ 42
Add Rolls ...................................................................................................................................... 42
Save Set......................................................................................................................................... 45
Edit Content Within a Set ............................................................................................................. 45
Blanks ........................................................................................................................................... 45
Rearrange Elements Within a Layer ............................................................................................. 46
Schedule and Communicate.......................................................................................................... 46
Advanced Communications .......................................................................................................... 57
Instant Commands ........................................................................................................................ 81
Appendix A-Player Setting INI Files ....................................................................................... 121
Appendix B-Editor Setting INI Files ................................................................................... 12115
Appendix C-Local Internet Weather Setup ............................................................................ 1210
Appendix D-Multi-Head Audio ........................................................................................... 12125
Appendix E-Data Acquistion ................................................................................................. 1216
Appendix F-Xwarp ................................................................................................................. 121
Appendix G-RSS Feeds ....................................................................................................... 12146
Appendix H-Warranty ............................................................................................................. 121
Keywest Technology
1
th
14563 W. 96
Terrace
Lenexa, Kansas 66215
23 Mar 2009
800.331.2019
Change 06
www.keywesttechnology.com
