S70 SERIES USERS MANUAL
Connect UPS to Utility and Charging
Before  the  initial  use  of  the  UPS,  plug  the  UPS  input  cord  into  a
wall  outlet  and  turn  the  UPS  on  by  depressing  the  Power  switch
on the front of the UPS. For best results, the batteries in the UPS
should  be  charged  for  at  least  6  hours  before  use.  The  UPS
charges  its  battery  while  it  is  connected  to  AC  utility  power  and
powered on.
Connecting the Loads
Plug  the  loads  to  be  supported  by  the  UPS  into  the  output
receptacles on the rear of the UPS. Simply turn the power switch
on  the  UPS  on  and  the
devices connected to the
UPS  will  be  protected  by
the UPS unit.
Connect Modem / Phone for Surge Protection
(S70 ‐1000, ‐1500, ‐2000 models only)
Connect a single modem/phone line into surge‐protected "IN" outlet on
the back of the UPS unit. Connect from "OUT" outlet to the computer
with phone line cable.
Connect Communication Cable
To allow for unattended UPS shutdown/start‐up and status monitoring,
connect one end of the communication cable to the USB port and the
other end to a USB port of a PC. With the monitoring software installed,
you will be able to schedule UPS shutdown/start‐up and to monitor the
UPS status through the PC.
Turn UPS ON / OFF
To  turn  the  UPS  unit  on,  press  the  Power  switch  on  the  front  of
 Xtreme Power Conversion® (XPC) Corporation                                 7
                                                                  V2
CAUTION:  NEVER  connect  a  laser
printer  or  scanner  to  the  UPS.  This
may cause damage to the unit.
