Operation

5.1

Activating the PCAN-Router Pro

After applying a supply voltage, the PCAN-Router Pro does a reset
and is initially inactive (sleep mode).
The standard equipment of the PCAN-Router Pro provides High-
speed CAN transceiver modules with wake-up function. Therefore it
is instantly activated (Power LED on).
If customized equipment does not include a CAN transceiver mo-
dule with wake-up function, the PCAN-Router Pro can be activated
with a connection between the positive terminal of the supply
voltage and pin 4 of port CAN 3 or CAN 4.
5.2

Default Bit Rates of the CAN Channels

In order to ensure the communication with the PCAN-Router Pro,
default bit rates are preset for CAN channels according to the used
CAN transceiver module.
Module name
CAN-HS
CAN-HS opto
CAN-HS-1041
(standard equipment)
CAN-LS
CAN-LS-SW
The default bit rate is enabled if the current configuration in the
PCAN-Router Pro does not provide another bit rate. In a configura-
Transmission standard
High-speed CAN ISO 11898-2
High-speed CAN ISO 11898-2
High-speed CAN ISO 11898-2
Low-speed CAN ISO 11898-3
Single-wire CAN SAE J2411
18
Default bit rate
500 kbit/s
500 kbit/s
500 kbit/s
125 kbit/s
33.3 kbit/s
