PCAN-Router Pro – User Manual
Data structures of the CAN messages for the real-time clock (ship-
ping configuration):
Function
CAN ID Data bytes
Setting
7F8h
RTC
Reading
7F9h
RTC
Y = year (2-digit), M = month, D = day, W = weekday (1 = Monday),
h = hour, m = minute, s = second, c = hundredth
YY MM DD WW hh mm ss 01
YY MM DD W0 cc ss mm hh
Remarks
Last byte = RTC update bit
Weekday on upper 4 bits
25
