Technical Specifications

Power supply
Supply voltage
Current consumption (at 12 V)
Wake-up time
Data logging
Medium
Maximum size of a trace
Storage requirement
Recording format
CAN
Standard transceiver
Other transceivers (on request)
Wake-up time
Termination
CAN ID reserved for
configuration transfer
12 V DC, 8 - 30 V possible
Idling: 65 mA
Maximum: 95 mA (4 channels to CF card)
Sleep mode: 470 μA
165 ms
CompactFlash card, max. 2 GByte
2 GByte
512 bytes per 25 CAN messages (independent of
the message lengths)
Proprietary binary format (*.btr), conversion
options with the provided Windows program:
- PCAN-Trace (*.trc)
- Vector Trace (*.asc)
- comma-separated values (*.csv)
High-speed CAN ISO 11898-2 with wake-up
function (TJA1041)
High-speed CAN ISO 11898-2 (TJA1040)
with galvanic isolation
Low-speed CAN ISO 11898-3 (TJA1054)
with wake-up function
Single-wire CAN SAE J2411 (TH8056)
with wake-up function
165 ms
Setup with switches on the board
CAN OFF
High-speed none
Low-speed
4.7 kΩ
Single-wire
9.1 kΩ
7E7h
34
ON
120 Ω
1.1 kΩ
2.1 kΩ
