PCAN-Router Pro – User Manual
Create the following entries (see also figure):
Field
Selection/Input
I/O Function
70h (Special Out)
I/O No
Routing 1 to CF All Forward all CAN messages from CAN channel
Default Value 3
Field
Selection/Input
I/O Function
70h (Special Out)
I/O No
Trace Enable
Default Value 15
Further logging possibilities with the I/O function
Routing 1 to CF Explicit
bit ID
Routing 1 to CF Exclude
excluding those with the given 11-bit ID
Explanation
Special functions of the PCAN-Router Pro
1 to the CF card.
Alternatively, you can select the CAN channels
2, 3, or 4, or create additional entries for these
CAN channels.
2-bit value, CAN frames with 11-bit and/or 29-
bit ID are forwarded to the CF card (here: both
ID types)
Bit 0 (1) = 11-bit ID
Bit 1 (2) = 29-bit ID
Explanation
Special functions of the PCAN-Router Pro
The logging function must be enabled for the
desired CAN channels.
4-bit value, a set bit enables the logging
function for the corresponding CAN channel
(here: all four CAN channels)
Bit 0 (1) = CAN 1
Bit 1 (2) = CAN 2
Bit 2 (4) = CAN 3
Bit 3 (8) = CAN 4
: Only CAN messages with the given 11-
: All CAN messages with 11-bit ID
31
70h (Special Out)
:
