PCAN-Router Pro – User Manual
I/O Function I/O Number
Trace Clear
Trace Buffer Type
Configuration ID 7E7h
enable
RTC Set Year
RTC Set Month
RTC Set Day of Month
RTC Set Day of Week
RTC Set Hour
RTC Set Minute
RTC Set Second
RTC Write
RTC Set Alarm
Logging error frames
enable
CAN x bitrate raw
CAN bitrate: xy
None
Const
(Diverse values)
(CCh)
Positive Const
0 to 255
(CDh)
Negative Const
0 to -255
(CEh)
Special In Conf Ver Main
(F0h)
Conf Ver Sub
Numbe
Value range Function
r of bits
1 0, 1 Erases the contents of the trace file
Determines the mode for logging:
2 1, 2 1 = linear: The logging stops when the trace file is full (default).
2 = circular: When the trace file is full, the logging restarts at the beginning.
Determines for each CAN channel if it can receive configuration messages via the CAN ID 7E7h (on for all
Value from bit
4 channels by default). At least one CAN channel must be selected for reception. Each of the four bits represents a
pattern (see right)
CAN channel (CAN 1 - CAN 4).
0 - 99
1 - 12
1 - 31
Declarations for date and time to set the battery-buffered real-time clock
Note: All declarations must be transmitted to the router.
1 = Mo ... 7 = Su
Initialization with the I/O function
0 - 23
0 - 59
0 - 59
1 0, 1 Initializes the real-time clock (RTC) with declarations from the I/O function
Sets the alarm time for activating the PCAN-Router Pro when it is in sleep mode
Value from bit Bit pattern:
32
pattern (see right)
--MMMMMM MMDDDDDh hhhhmmmm mmssssss
M = month, D = day of month, h = hour, m = minute, s = second
Value from bit Determines for each CAN channel if occuring error frames are recorded with the enabled logging function. Each
4
pattern (see right) of the four bits represents a CAN channel (CAN 1 - CAN 4).
Sets the CAN bit rate for CAN channel x by the register values for the CAN controller (compatible to SJA1000 at
16 0x0000 - 0xFFFF
16 MHz)
0 - 3
Sets a CAN bit rate xy for the given CAN channel
(CAN channel 1 - 4)
No function
Can be used as place-holder if the corresponding input or output has no function.
Diverse constants
Read only; can be used as input constants
Positive constants
Read only; can be used as input constants
Negative constants
Read only; can be used as input constants
8 0 - 255 Main version number of the configuration
Secondary version number of the
8 0 - 255
configuration
Special Out (70 h) > RTC Write
Can be specified in the PPCAN-Editor during the module-
specific settings
40
Special Out (70h) > RTC Set
