PCAN-Router Pro – User Manual
CAN property
ID
Data length
Transmit cycle
time
RTR
Format
Data
Position
Length
(byte:bit)
(bits)
0:0
32
4:0
32
Message GetTraceInfo_R
7F1h
8 bytes
none (0 ms)
yes
Intel (Little Endian)
See following table
Name of data variable
CFTraceFileMsgFree
CFTraceQueueOverruns
Description
Number of CAN messages still
fitting into the trace file
Number of CAN message not being
processed by the CF card queue
due to overload
21
