PCAN-Router Pro – User Manual
Aluminum profile casing with mounting flange
Option for mounting on top hat rails
Customized firmware available on request
Extended operating temperature range of -40 to +85 °C (-40 to
+185 °F)
1.2

Prerequisites for Operation

Voltage supply 8 – 30 V DC (e.g. car battery)
For configuring via CAN:
• Computer with CAN interface of the PCAN series (e.g.
PCAN-USB)
• CAN cabling with correct termination
• Windows 7/Vista/XP (32/64-bit) for the configuration
program
For converting logged CAN data:
• Computer with card reader for CompactFlash cards
• Windows 7/Vista/XP (32/64-bit) for the converter program
• Sufficient space for data on the hard disk (up to 5 times of
the initial file size from the CompactFlash card, e.g.
1 GByte + 4 GByte)
6
