PCAN-Router Pro FD – User Manual
8 - 32 V power supply, protection against overvoltage and
reverse polarity
Slot for a backup battery for defined switch-off behavior (e.g. for
log data saving)
Optional on request:
Ethernet interface via RJ-45 socket or BroadR-Reach® interface
via D-Sub connector
Extended operating temperature range from -40 to 85 °C
(-40 to 185 °F)
1.2

Operation Requirements

The transfer of the firmware via CAN requires a PEAK CAN
interface
1.3

Scope of Supply

PCAN-Router Pro FD in aluminum casing including mating
connectors for I/O and power
USB connector cable
Windows development package with GCC ARM Embedded,
flash program, and programming examples
Conversion software PEAK-Converter for Windows 10, 8.1, 7
(32/64-bit)
Manual in PDF format
