PCAN-Router Pro – User Manual
3.1 Using an Alternative CAN Transceiver
Module
For each of the four CAN connections an alternative CAN transcei-
ver module can be inserted on request.
Following modules are available:
Module name Transmission
standard
CAN-HS High-speed CAN
ISO 11898-2
CAN-HS opto High-speed CAN
ISO 11898-2
CAN-HS-1041 High-speed CAN
(standard) ISO 11898-2
CAN-LS Low-speed CAN
ISO 11898-3
CAN-LS-SW Single-wire CAN
SAE J2411
The PCAN-Router Pro automatically detects the type of the inserted
CAN transceiver module and adjusts the default bit rate for the CAN
channel. The bit rate can be changed by a configuration.
Special Used CAN
function lines
CAN_L, CAN_H 500 kbit/s
Galvanic CAN_L, CAN_H 500 kbit/s
isolation up to
300 V for the
CAN interface
Wake-up CAN_L, CAN_H 500 kbit/s
Wake-up CAN_L, CAN_H 125 kbit/s
Wake-up CAN_SW
11
Standard bit
rate
33.3 kbit/s
