6.7 Recalling the manufacturer defaults

From the main screen press ENTER until the password screen is shown:
•
Enter the password 50
•
The message dEF is displayed, fl ashing
Confi rm by pressing ENTER or exit by pressing ESC
If no button is pressed for 30 seconds, the display returns to the main
screen.

6.8 Visualization release Software

1) when swith-on the unit to display "rel. x.y "(example rel. 1.0)
2) during operation
a) to display: by main mask press ESC and UP appear in sequence: the size
dell'umidifi catore, the voltage, the number of phases and the software
release
b) the network by means of variable whole 81. Es. format = # # #. # "(eg., 12
= release 1.2)"
6.9 Match digit (match between the softwares
of board and terminal)
humiSteam basic verifi es the matching between the softwares of the
controller and the terminal at the start-up. The 8th digits for board and 9th
for terminal of both codes must be equal.
If there is no match, on power-up after displaying the software release, and
in normal operation when pressing UP+PRG, the red LED will remain on for 5
seconds, and the following error message will be displayed:
"X – Y", where "X" and "Y" are the 2 diff erent 8th digits. Refer to the after-sales
service.

6.10 Reset cylinder hour counters

•
Access parameter 'da' (see chap. 7)
•
press UP and DOWN for 5 seconds
When the counter has been reset, the display shows 'res' .
6.11 Parameters: Saving/recalling the user
settings
From the main screen, a copy of the user settings can be saved at any time,
and then later recalled.
To save the settings::
From the main screen press:
•
ENTER for 2 seconds,
•
enter the password 51 using the UP or DOWN button and press ENTER, the
message UbP (Backup User parameters)
•
press ENTER: the message -L- is displayed, fl ashing
•
press UP or DOWN, the message–S- (Save) is displayed, fl ashing,
•
press ENTER to save a copy of the user settings, or press ESC to cancel the
operation
NOTE: the copy of the user parameters saved previously will be overwritten
with current user settings.
To recall the settings::
From the main screen press:
•
ENTER for 2 seconds,
•
enter the password 51 using the UP or DOWN button and press ENTER,
the message UbP (Backup User parameters)
•
press ENTER: the message -L- (Loading) is displayed fl ashing,
•
press ENTER to recall the previously saved copy of the user settings, or
press ESC to cancel the operation.
If no button is pressed for 30 seconds, the display returns to the main
screen, without performing the operation.

6.12 Manually drain the water in the cylinder

Total drain in operation
Press UP and DOWN together for 2 seconds (the message 'dr' on the display
alternating with 'tot' indicates the function has been activated). Press UP
and DOWN again for 2 seconds to stop the drain cycle. The drain cycle in
any case ends automatically.
