Fittings provided for the water connections:
Models UE001 to UE018
B
A
Hydraulic interfaces dimensions
Interfaces dimensions drain/fi ll
dimensions mm (in) UE001 to UE018
D
72.6 (28.6)
D'
125.4 (49.4)
E
52.6 (20.7)
E'
107.5 (42.3)
Interfaces dimensions
steam outlet and condensed drain
dimensions mm (in) UE001 to UE018
F
126.7 (50.0)
F'
224 (88.2)
G
137.9 (54.3)
G'
21.7 (8.6)
Interfaces dimensions drain/fi ll
dimensions UE025 to UE045
mm (in)
I
40 (15.8)
I'
72 (28.3)
I''
10.2 (4.0)
L
123.2 (48.5)
L'
231.2 (91.0)
L''
49.1 (19.3)
L'''
678 (26.7)
Interfaces dimensions
steam outlet and condensed drain
dimen. UE025 to UE045
mm (in)
M
172 (67.7)
M'
30.2 (11.9)
N
181 (71.3)
N'
---
N''
55 (21.7)
* 230 Vac models only
Models UE025 to UE065
D
A
B
C
Fig. 2.b
UE045* to UE065
752(29.6)
UE045* to UE065
223.7 (88.1)
30.2 (11.9)
181 (71.3)
100 (39.4)
61 (24.0)
Key:
A.
supply water inlet
B.
drain water outlet
C.
bottom tank drain water outlet (models
UE025 to UE065 only)
D.
supply water inlet drain tempering valve
