Step Action
Proceed according to the
media type:
Die-cut – peel media from
•
the backing and place the
backing under the Sensor
Eye Mark then press the
key.
Notched – place the notch
7 •
under the Sensor Eye Mark
then press the
Reflective – place the black
•
mark facedown under the
Sensor Eye Mark then press
the key.
Continuous – go to Step 8.
•
Position the label (and
backing, if any) under the
8 sensor then press the
key.
9 Observe the LCD.
Press the
times to exit the menu.
Load media. Position the Media
10
Sensor. Press and hold the
Key until at least
one label advances.
Adjustments and Maintenance
Displayed Message
SCAN BACKING
PRESS ESC KEY <yyy>
Or, for reflective media:
key.
PRESS ESC KEY <yyy>
SCAN PAPER
PRESS ESC KEY <yyy>
CALIBRATION COMPLETE
Or, for reflective media:
REFLECTIVE MODE
CALIBRATION COMPLETE
Or, for continuous media:
CONTINUOUS MODE
CALIBRATION COMPLETE
Key three
SCAN MARK
GAP MODE
READY
2-3
Comment
Never position a perforation
in the sensor when
recording a reading.
This sets the backing, gap,
or mark value where "yyy"
is the current sensor
reading.
If using preprinted media
ensure that the sampled
label area is free of
preprinted text, graphics or
borders.
This sets the paper value,
where "yyy" is the current
sensor reading.
The calibration was
successful if CALIBRATION
COMPLETE appears.
Also, WARNING LOW
BACKING is a normal
message when calibrating
notched media or media on
a transparent backing; see
Section 3.3 for other
possible messages.
The printer is ready.
If this calibration was
unsuccessful, go to Section
2.1.3.
