Datamax H Class Operator's Manual page 127

Displayed
Message
TEMPERATURE The printer has shutdown to
FAULT allow the printhead
temperature to cool.
The printer could not find a
TOP OF FORM
FAULT TOF mark within the
maximum length setting, or a
TOF was encountered in an
unexpected place.
Note: When the SENSOR
TYPE is REFLECTIVE, this
indication is given for an out
of stock condition.
Description
119
Possible Solution(s)
Make sure the printer is placed within a
acceptable environment. Turn OFF the
printer and wait until the printhead cools
sufficiently to prevent permanent damage.
•
It may be necessary to calibrate the
printer.
•
The Media Sensor may need to be
positioned.
•
The Media Guide may need to be
positioned.
•
The Leveling Cam may need
adjustment.
•
The maximum label length setting may
need to be increased for longer label
sizes.
•
The Media Sensor may need to be
cleaned.
After performing the corrective actions, press
the FEED Key to clear the fault. If the fault
does not clear, call for service.
