4.4 ExpressCard

4.4 ExpressCard

Removing the ExpressCard

To remove the ExpressCard, follow the steps below and refer to Figure 4-3.
CAUTION: Before you remove the ExpressCard, refer to the card's documentation and
to your operating system documentation for proper procedures and
precautions.
1. Push the ExpressCard. It will pop out partly, so pull out the card.
Installing the ExpressCard
To install the ExpressCard, follow the steps below and refer to Figure 4-3.
1. Insert the ExpressCard and press it until it is securely connected.
PORTÉGÉ R830/Satellite R830 Maintenance Manual (960-880)
Figure 4-3 Removing the ExpressCard
4 Replacement Procedures
ExpressCard
[CONFIDENTIAL] 4-13
