Intel R1000GZ Technical Product Specification page 59

Error: Displays the last active system event. The last active event may be degraded, non critical or critical

only. It will not display an informational message. If the system is healthy then displays "System Health
Ok".
BMC IP: Displays the IPv4 or IPv6 address of BMC IP. If the BMC IP address is not configured, then

nothing is displayed.
RMM4 IP: Displays the IPv4 or IPv6 address of RMM4 dedicated LAN IP. If the RMM4 IP is not set or not

present, then nothing is displayed.
Power: Displays the current system power consumption in watts. The power consumed will be refreshed

every minute.
Last PC: Displays last BIOS post code.

Custom string: Displays a customizable text string. The custom text string is modifiable through BIOS

setup.
Custom Logo: Displays a customizable bitmap logo. The OEM customized logo is programmed by the

OEM and will be maintained during subsequent firmware updates.
®
