Power Supply Fans; Frusdr Utility; Table 19. System Fan Connector Pin-Out - Intel R1000GZ Technical Product Specification

SYS_FAN 1
Signal Description
FAN_TACH1_IN
FAN_BMC_PWM0_R_BUF
P12V_FAN
P12V_FAN
FAN_TACH0_IN
GROUND
GROUND
FAN_SYS0_PRSNT_N
LED_FAN_FAULT0_R
LED_FAN0
SYS_FAN 4
Signal Description
FAN_TACH7_IN
FAN_BMC_PWM3_R_BUF
P12V_FAN
P12V_FAN
FAN_TACH6_IN
GROUND
GROUND
FAN_SYS3_PRSNT_N
LED_FAN_FAULT3_R
LED_FAN3
4.4

Power Supply Fans

Each installed power supply module includes one embedded (non-removable) 40-mm fan. It is responsible for
airflow through the power supply module. This fan is managed by the fan control system. Should this fan fail,
the power supply will continue to operate until its internal temperature reaches an upper critical limit. The
power supply will be protected against over temperature conditions caused by loss of fan cooling or excessive
ambient temperature. In an over-temperature protection condition, the power supply module will shutdown.
4.5

FRUSDR Utility

The purpose of the embedded platform management and fan control systems is to monitor and control various
system features, and to maintain an efficient operating environment. Platform management is also used to
communicate system health to supported platform management software and support mechanisms. The
FRUSDR utility is used to program the server board with platform specific environmental limits, configuration
data, and the appropriate sensor data records (SDRs), for use by these management features.
The FRUSDR utility must be run as part of the initial platform integration process before it is deployed into a
live operating environment. It must be run with the system fully configured and each time the system
configuration changes.
The FRUSDR utility for the given server platform can be run as part of the Intel
and Management DVD that ships with each Intel server, or can be downloaded from Intel.com.
Note: The embedded platform management system may not operate as expected if the platform is not updated
with accurate system configuration data. The FRUSDR utility must be run with the system fully configured and
each time the system configuration changes for accurate system monitoring and event reporting..
28
®
Intel Server System R1000GZ/GL Product Family TPS

Table 19. System Fan Connector Pin-out

SYS_FAN 2
Pin# Signal Description
1 FAN_TACH3_IN
2 FAN_BMC_PWM1_R_BUF
3 P12V_FAN
4 P12V_FAN
5 FAN_TACH2_IN
6 GROUND
7 GROUND
8 FAN_SYS1_PRSNT_N
9 LED_FAN_FAULT1_R
10 LED_FAN1
SYS_FAN 5
Pin# Signal Description
1 FAN_TACH9_IN
2 FAN_BMC_PWM4_R_BUF
3 P12V_FAN
4 P12V_FAN
5 FAN_TACH8_IN
6 GROUND
7 GROUND
8 FAN_SYS4_PRSNT_N
9 LED_FAN_FAULT4_R
10 LED_FAN4
Revision 1.1
SYS_FAN 3
Pin# Signal Description
1 FAN_TACH5_IN
2 FAN_BMC_PWM2_R_BUF
3 P12V_FAN
4 P12V_FAN
5 FAN_TACH4_IN
6 GROUND
7 GROUND
8 FAN_SYS2_PRSNT_N
9 LED_FAN_FAULT2_R
10 LED_FAN2
SYS_FAN 6
Pin# Signal Description
1 FAN_TACH11_IN
2 FAN_BMC_PWM5_R_BUF
3 P12V_FAN
4 P12V_FAN
5 FAN_TACH10_IN
6 GROUND
7 GROUND
8 FAN_SYS5_PRSNT_N
9 LED_FAN_FAULT5_R
10 LED_FAN5
®
