Item Description
Emulation The emulation type.
Concatenation The RAID concatenated parity group number. A hyphen (-) is indicated when the parity group
is not RAID concatenated.
Encryption The status of the encryption setting.
0-31: Encryption Key ID Disable: Disabled.
LDKC:CU:LDEV The LDKC number, the CU number, and the LDEV number.
Size The capacity of CV.
Unit The unit of the capacity of CV.
System Disk The status of the system disk setting.
Disable or Enable will appear.
SSID The subsystem ID.
MPB The ownership of the MPB.
Num. of LDEVs The number of LDEVs.
Num. of PGs The number of parity groups.
B4 The B4 number.
SPARE The spare drive number.
Num. of SPAREs The number of spare drives.
Note: Only the changed items will be output. The Detailed Information of the recovery process will not be output when
the installation process executed before the process has completed. However, the setting of the recovery process will
be output as the Detailed Information of the process when the installation process executed before the recovery process
has not completed.
Example 3: installing additional cache memory
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,SVP,uid=user-name,1,,
[Install],Install,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{CM,CMG,size,SSD0,SSD1)}
=[{1CA/2CC,C16G,32768,BM64(64GB),0},
{1CB/2CD,C16G,32768,BM64(64GB),0},
{1CE/2CG,C16G,32768,BM64(64GB),BM64(64GB)},
{1CF/2CH,C16G,32768,BM64(64GB),BM128(128GB)}],Num. of CMs=4
+Cache Residency available Size=3328
+{CLPR,Cache size,Cache Residency size,ExtentNumber}
=[{CLPR0,117760,6656,16384}],Num. of CLPRs=1
+PP Flag=[<64KLDEV, SI/VM Extension1, FCV2, DP, CoW, TPF>,
<SI/VM Extension2, CoW Extension>],Num. of PP Flags=2
+Max Number of CUs=255
Detailed Information for Example 3
Item Description
CM The mounting location of the PCB for cache memory.
CMG The capacity of CMG.
Size The capacity of cache memory.
SSD0 The size of SSD0.
SSD1 The size of SSD1.
