Detailed Information
Item
M-VOL(LDKC:CU:LDEV)
R-VOL(LDEV)
S/N
LDKC
SSID
Controller ID
Type
Initial Copy
Fence Level
Copy Pace
Priority
Diff
CFW
DFW
TS
Result
Num. of Pairs

[Cnt Ac-S Z] Change Option

Example
07xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,RMI AP,uid=user-name,1,,
[Cnt Ac-S Z],Change Option,,Normal end,
from=xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx,,Seq.=xxxxxxxxxx
+{Max Initial Copy,CU Activity,Path Blockade Watch(s),
Path Blockade SIM Watch(s),Service SIM}={128,Enable,45,070,
Not Report}
+{LDKC,CU,Service SIM,PPRC Support,SCP Time(s),Max Initial Copy}
=[{0x00,0x00,Not Report,Yes,600,04},
{0x00,0x01,Not Report,Yes,600,04},
{0x00,0x02,Not Report,Yes,600,04},
{0x00,0x03,Not Report,Yes,600,04},
{0x00,0x04,Not Report,Yes,600,04},(snip)-(snip)],Num. of CUs=255
Description
The LDKC, CU, and LDEV numbers of the volume specified to the main volume when the
pair is created.
The LDEV number of the volume specified to the remote volume when the pair is created.
The serial number of the device.
The LDKC number of the paired LDKC.
Indicates SSID.
The controller ID.
The update copy mode set; Sync: Synchronous mode
The initial copy mode set; Entire: Copy all, None: Do not copy.
The fence level set (the condition that MCU rejects the write operation to the main volume.)
Never: No condition, Data: S-VOL data, Status: S-VOL status.
The initial copy speed set (the number of tracks you can copy at a time).
The priority of the initial copy operation set (scheduling order).
The unit of the differential management set: Auto, Cylinder, Track.
Indicates whether the setting to copy the CFW data to the remote volume is enabled or
not. Only M-VOL: Copy to main volume only is enabled Copy to R-VOL: Copy to main and
remote volume is enabled.
Indicates whether DFW use to the remote volume is set or not.
Not Required: DFW not required, Required: DFW required
Indicates whether or not the host I/O time stamp is transferred to R-VOL when the pair is
created.
Enable: transferred, Disable: not transferred
The result of operation.
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
The number of created pairs.
Continuous Access Synchronous Z Descriptions 153
