Lexmark Optra C710 Service Manual page 91

5016-001
Message
70–79 Network
83 Transfer Belt
Life Warning
84 Transfer Belt
Life Warning
84 Transfer Belt
Exhausted
85 Coating Roll
Life Warning
86 Transfer Belt
Missing
Status
Reserved for messages
relating to the optional
print server sometimes
referred to as an Internal
Network Adapter (INA)
installed in your printer.
This message indicates
the waste toner area is
full.
This message indicates
the transfer belt is nearing
its end of life. The transfer
belt is a part of the
transfer kit. If you do not
have an extra transfer kit,
order it now.
This message indicates
the transfer belt is
exhausted and must be
replaced.
This message indicates
the coating roll is nearing
its end of life or empty
condition. Normally the
coating roll is replaced
when you replace the
black print cartridge. It is
possible, depending on
the type of print jobs you
send to the printer, a
coating roll may have to
be replaced prior to the
print cartridge becoming
low on toner. If you do not
have an extra coating roll,
order it now.
The transfer belt is not
installed in the printer.
Action
For more information, refer
to the online documentation
included on the printer CD
under "Network Printing."
If you suspect a false waste
toner full condition has
occurred, you can clean the
waste toner sensor.
Press to clear the
Go
message and continue
printing. The
Supplies
status message displays
with the ,
Ready
, and
Saver Busy
messages, unless another
status message of higher
priority is posted, or until
you replace the transfer belt.
A new transfer belt must be
installed to clear this error
message.
Press to clear the
Go
message and continue
printing. The
Supplies
status message is displays
with the ,
Ready
, and
Saver Busy
messages, unless another
status message of higher
priority is posted, or until
you replace the coating roll.
Note: Continued use of the
coating roll after the warning
has been displayed may
result in poor toner adhesion
to print media, other print
quality problems, and paper
jams.
Insert the transfer belt and
close the front cover to clear
the message.
Diagnostic Information
Power
Waiting
Power
Waiting
2-25
