1
Turn the printer off. Open the front cover.
2
Remove all the print cartridges.
a
Pull up slightly on the cartridge handhold.
b
Pull the cartridge straight out and use the handle to lift it off the guides.
www.lexmark.com
Lexmark C750
Clearing image transfer unit jams
1
Advertisement
Related Manuals for Lexmark C750
Summary of Contents for Lexmark C750
- Page 1 Turn the printer off. Open the front cover. Paper handling Maintenance Troubleshooting Administration Remove all the print cartridges. Pull up slightly on the cartridge handhold. Index Pull the cartridge straight out and use the handle to lift it off the guides. www.lexmark.com Lexmark C750...
- Page 2 Clearing image transfer unit jams Printing Place the cartridges on a clean flat surface out of direct light. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 3 Clearing image transfer unit jams Printing Release the latches to open the multipurpose feeder all the way. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 4 Clearing image transfer unit jams Printing Remove the image transfer unit. Raise the lever to unlock the image transfer unit. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 5 Clearing image transfer unit jams Printing Pull down on the handle. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 6 Printing Slide the image transfer unit out and place it on a clean, flat surface. Warning: Do not touch the transfer belt. Touching the belt will damage the image Paper handling transfer unit. Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 7 Clearing image transfer unit jams Printing Look inside the printer. Remove all torn paper or other jams. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 8 Clearing image transfer unit jams Printing Insert the image transfer unit back into the printer. Align the guides with the insertion grooves. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 9 Clearing image transfer unit jams Printing Push the handle up using both hands, and gently slide the unit in. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 10 Clearing image transfer unit jams Printing Lower the lever to lock the image transfer unit into place. Paper handling Maintenance Troubleshooting Administration Return the multipurpose feeder to its working position. Index www.lexmark.com Lexmark C750...
- Page 11 Clearing image transfer unit jams Printing Reinstall all the print cartridges. For helping installing the print cartridges, refer to the Lexmark C750 Setup Guide or Publications CD. Paper handling Maintenance Troubleshooting Administration Index www.lexmark.com Lexmark C750...
- Page 12 Clearing image transfer unit jams Printing Close the printer door. Paper handling Maintenance Troubleshooting Turn the printer on. The printer returns to a Ready state. Administration Index www.lexmark.com Lexmark C750...
