Lexmark Optra C710 Service Manual page 341

5016-001
Assembly 25:
Asm. Part
Index number
25 - 1 12G1150
2 12G1400
3 12G1401
4 12G1403
5 12G1688
6 12G1259
7 12G1690
8 12G1456
9 12G1477
10 12G1472
11 12G1413
12 12G1458
13 12G1483
14 12G1654
15 12G1455
16 12G1412
17 12G1223
18 12G1402
19 12G1090
20 12G1370
21 12G1457
22 12G1474
23 12G1655
24 12G1409
25 12G1405
26 12G1414
27 12G1415
28 12G1404
29 12G1399
30 12G1293
31 12G1333
32 12G1468
Units Description
1 Plate, Transfer Lower Guide
1 Roller, Reverse
2 Roller, Sub Plate Asm.
1 Roller, A
1 Pin, Dowel, Roller A
1 Shaft, Gear
1 Pin, Dowel, Gear Shaft
2 Gear, (20Z)
10 Bushing, Guide Frame Asm.
1 Belt, Timing, (40S2M710)
1 Pulley, (25T)
1 Gear, Idle, (20P)
4 Bushing
2 Plate Asm., Sub
2 Gear (18)
1 Pulley, Left (25T)
4 Sheet Slide
1 Roller, Feed, 2
1 Plate, Side, Right
3 Spring, Pressure
1 Gear, (20Z)
1 Belt, Timing, (35S2M448)
1 Frame Asm., Guide
1 Pulley, (20T)
3 Roller, Idler
2 PUlley, S (20T)
1 Pulley
2 Roller, B
1 Roller, Feed, 1
1 Lever, Sensor
1 Spring, Sensor Lever
1 Belt, Timing, (40S2M800)
7-71
Parts Catalog
