C-2

PC settings for all operating systems

This section describes how to configure the ECP parallel port.

Configuring the ECP parallel port

For most PCs, the parallel port is configured as an ECP parallel port in the PC's BIOS.
The following applies to some PCs and to the Windows 2000, Windows NT, Windows
Me, and Windows 98 operating systems.
i
Configure the ECP parallel port
1
2
3
4
5
Set up two ECP parallel ports
1
i
2
3
4
See the information that accompanies your PC for details about changing the
BIOS settings.
Close all open applications.
Reboot the PC. Observe the screen for instructions on entering Setup.
Enter Setup and follow the instructions that display early in the reboot sequence.
The setup screen will appear.
In Setup, check to see that the Parallel Port Mode field is set to ECP. If it is not, set
it to ECP.
i
If the PC has more than one parallel port, make sure you check the setting for
the parallel port to which the printer is attached (LPT1 or LPT2).
i
An ECP port is required for the printer to operate at its maximum processing
speed. The printer will operate in compatible or IBM AT mode; however, the
printer might not operate as fast.
Save the setting and exit Setup, following the instructions in the setup screen.
Continue with the "Set port values" procedure for your operating system.
Follow the instructions provided with the port to install it and set the jumpers.
Record the jumper settings.
The jumper settings must match the settings you choose in the Resources tab.
Right-click on the My Computer icon on the desktop and then select Properties
from the popup menu. The System Properties dialog box appears.
Select the Device Manager tab to view a list of devices.
Select "View devices by type" if needed.
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
