Cleaning kits

Cleaning kits include 5 printer cleaning cards and 5 replaceable cleaning sleeves. The
following cleaning kits are available:
Printer features
For printers with magnetic stripe modules
For printers without magnetic stripe modules

Magnetic stripe cleaning card

Use the magenetic stripe cleaning card if the printer has a magnetic stripe module.
The card is part number 590408-002.
!
excessive wear can result.

Cleaning pen

To maintain print quality and prolong the life of the printhead and other parts, use a
cleaning pen. The cleaning pen is part number 557492-001. Each pen can be used
eight times.
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Figure B-4: Replaceable cleaning sleeve
Do not use the magnetic stripe cleaning card more than once every 2000 cards or
Part number
549718-001
549717-001
Figure B-5: Cleaning Kit
B-7
