2-4

Loading the print ribbon

The printer uses print ribbon with color panels, continuous color, or color and topcoat.
Full-color ribbon (such as YMCKT) must be Premium ribbon, which uses blue ribbon
spools. Monochrome (one color) ribbon on teal ribbon cores can also be used. (Full-
color ribbon on teal cores cannot be used.)
i
The type of print ribbon you use must match the print ribbon setting in the driver.
To order new ribbon, contact your service provider. See "Supplies and cards" on
page B-1 for information about ribbons available.
Remove the print ribbon cartridge
1
2
Lift the top cover, as shown in Figure 2-5.
Press down on the swing arm until it clicks (step 1 in Figure 2-6). The push latch
releases the swing arm. Lift the swing arm until it is fully open (step 2 in
Figure 2-6).
Figure 2-6: Open the swing arm
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Figure 2-5: Open the cover
2
1
Using the printer
