Maintaining the printer
3
User's Guide for ImageCard® Select™ and UltraGrafix® Select™ Printers
Figure 4-7: Clean the pick rollers
c Click the "Printer" button in the Clean area. Click OK on the prompt that
appears. Do not insert a cleaning card! The driver sends a command to the
printer to run the printer cleaning card. The printer moves rollers when it
attempts to pick the card.
d Slowly move the pen on the pick roller.
e Lightly wipe any dirt from the end of the cleaning pen onto a clean cloth or
paper. Move the cleaning pen to another area of the roller.
f Repeat steps c through e until no more dirt appears on the pen.
g Repeat steps c through f, placing the cleaning pen on the second pick roller
(step 2 in Figure 4-7).
Clean the transport area rollers:
a Open the cover and remove the print ribbon cartridge. The card cartridge
should stay out of the printer.
b Place the cleaning pen on top of the first transport roller (location 1 in
Figure 4-8).
Figure 4-8: Clean rollers in the card track
2
1
1
3
2
