3.6.2

Validation Forms Printing

The Models 93PLUS and 94PLUS are both equipped with independent validation. The movement of the
validation form is under software or firmware control and allows the form to move either independent of the
receipt (or receipt/journal) or in sync with the receipt (or receipt/journal).
Lines per inch
9
8.5
8
6

Table 3 Validation lines

Lines per inch
9
8.5
8
6

Table 4 Ten line validation option

Figure 9 Validation print with normal and narrow print zones

3.6.2.1
Form insertion is from the top or the left side of the printer. Automatic form location is under software
or firmware control. Character rotation under software control will allow check validation to appear
right-side up when the check is removed.
11/07/05
PcOS Series 90PLUS
Lines
18
17
16
13
Lines
11
10
10
7
2.40"/2.80"
(61.0/71.1 mm)
6.00 - 10.00"
(152.4 - 254.0 mm)

Validation Forms Insertion

0.50" (12.7 mm)
2.50 - 4.25" (63.5 - 108.0 mm)
0.625"
(15.9 mm)
