Programmer's Guide

3.6 Printable Area

3.6.1

Receipt Printing

3.6.1.1
2.80" (71.1 mm)
3.25" (82.6 mm)

Figure 6 Receipt printable area

The paper tear-off is 0.7 inch (17.78 mm) above the last line of print. To place the last line printed
above the tear-off point, the paper should be fed 0.8 inch (20.32 mm). The paper can then be torn-off
from either the left or right side. The first line of the next print will be 0.7 inch (17.78 mm) from the
top of the form.
The paper should not be reverse fed back into the printer. If a double-high line of print is the first line
of a receipt, it will be reverse fed 0.1 inch (2.54 mm). If any more paper is reverse fed, the paper will
become unloaded from the tear-off bar.
11/07/05
PcOS Series 90PLUS

Receipt Printing without the Autocutter

Tear-off
0.70" (7.8 mm)
0.225" (5.7 mm)
2.40" (61.0 mm)
2.50" (63.5 mm)

Figure 7 Receipt printable area

Rev Q
General Specifications
Tear-off
0.70" (17.8 mm)
0.225" (5.7 mm)
Page 11
