Vertical Motion - TransAct Ithaca 90PLUS Series Programmer's Manual

Programmer's Guide
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Note
11/07/05
PcOS Series 90PLUS
Set line space 21/216 or 7/72 inch
[ESC] 1
1BH 31H
<27> <49>
&%SG
none
The [ESC] 1 command sets the default line spacing to 21/216 inch. The line spacing
is for all-points-addressable (APA) graphic printing.
Set variable line space n/72 inch
[ESC] A <n>
1BH 41H <n>
<27> <65> <n>
none
none
The [ESC] A <n> command sets the default line spacing to n/72. Set n = 1 to 85. The
line spacing does not take effect until enabled by the [ESC] 2 command. The
command is provided to maintain backward compatibility with the Series 50,
OKIDATA, IBM, and other printers. It can also be used to print on preprinted forms.
Enable [ESC] A <n> line spacing
[ESC] 2
1BH 32H
<27> <50>
none
none
The [ESC] 2 command enables [ESC] A <n> line spacing. [ESC] 2 is a companion to
the [ESC] A <n> command and puts the specified line spacing into effect. It will
remain in effect until another line spacing command is issued.
Feed <n> lines at current spacing
[ESC] d <n>
1BH 64H <n>
<27> <100> <n>
&%FL <m > <m >
1 2
[ESC] d
The [ESC] d <n> command prints the contents of the buffer (if any) and performs
<n> line feeds at the current line spacing. The command does not change the default
line spacing value. The next character print position is reset to the left margin.
The IPCL command will print from 00 to 99 lines. For example, if you wish to feed
12 lines, the IPCL command would be as follows: &%FL12.
Rev Q
Printer Control Codes

Vertical Motion

Page 23
