Operator Panel Controls

6 Operator Panel Controls

6.1 Push Buttons - Momentary Switches

The RELEASE key opens and closes the validation clamp. It cycles through three modes: open, closed, and jam
removal. If the RELEASE key is held for two seconds, the slip drive will be activated. Activating the slip drive
is useful for removing jammed slips.
The FEED key advances the receipt and journal paper. If the FEED and RESUME keys are pressed together, the
receipt and journal paper will feed in a reverse direction.
The RESUME key restarts the printer after a validation load failure has been cleared.

6.2 Indicators

There are two indicators. One is READY and the other is FORM (status). The ready indicator is tricolored: red,
green, or orange. The printer can be in any of the following states:
STATE
Ready (The printer is ready to receive data and print).
Printer not ready (Cover is open).
Ready but waiting for a form
Request slip form
Request validation form
Request form be removed
Ready but low on receipt paper
Printer errors
Out of paper
Slip load failed
Printer fault (See 6.3 Fault Indicators).
Menu mode
Test mode
Printer failure
Watchdog fault (printer resets)

Table 19 Printer states

Page 112
PcOS Series 90PLUS
Rev Q
Programmer's Guide
READY
Indicator
green
flashing green
orange
flashing orange/green
flashing orange
flashing red
flash orange/green/red
flash red/orange
orange
FORM
Indicator
off
off
(status)
slow flash
fast flash
med. flash
off
off
slow flash
off
off
off
off
