Programmer's Guide
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
11/07/05
PcOS Series 90PLUS
Set rotated print line spacing
[ESC] u <n > <m > <n > <m
1 1 2
1BH 75H <n > <m > <n > <m
1 1 2
<27> <117> <n > <m > <n
1 1
none
none
The command adjusts the line spacing for each rotated print line, where n
line number and m is the spacing in dot columns (1/80 inch) from the previous
i
line.
L e ft m a r g i n
n = 1 , m
n = 2 , m

Figure 19

For the first print line, the distance is calculated from the margin. An n
0 is used to terminate the command. Any unspecified spacing will be set to one,
which allows data to be accurately positioned on an inserted form. These values
will be used as a template for all subsequently rotated print. On power up, all
spacing is preset to 1/80 inch (n = 1, eight lines per inch) for all lines. The
command is only effective in 90° and 270° rotation modes. The command
remains in effect until a new table is received or until the printer is power cycled.
An [ESC] u <0> will have the effect of setting all lines to 1. The table can be
overridden by [LF] or [ESC] J <n> commands in the rotated print data.
The value of m can be from 1 to 127; n can be from 1 to 22.
Table 13 on page 42 specifies the line spacing for the command.
Rev Q
Printer Control Codes
Print Rotation Commands
> ... <n > <m > <0>
2 i i
> ... <n > <m > 00H
2 i i
> <m > ... <n > <m > <0>
2 2 i i
E d g e o f f o r m
F i r s t l in e
S e c o n d l i n e
T h i r d l in e
is the
i
value of
i
Page 47
