Printer Control Codes
Vertical Motion

5.2 Vertical Motion Control

Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
EPOS Note
Example of Fine Line Feed[CR]
[ESC]J<54>
This line is
[CR][LF]
This line is spaced at the default
of 1/8". [CR][LF]

Figure 13 Data sent to printer for a fine line feed

Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
EPOS Note
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
EPOS Note
Page 22
PcOS Series 90PLUS
Fine line feed
[ESC] J <n>
1BH 4AH <n>
<27> <74> <n>
&%FM <m > <m > <m
1 2
[ESC] J <n>
The [ESC] J <n> function command prints the contents of the buffer (if any) and
performs a line feed of n/216 inch. The command does not change the default line
spacing value. The next character print position is reset to the left margin if the auto-
CR mode is set.
In EPOS mode, the command performs line feeds in n/144-inch increments.
1/4" below the first.
Set variable line space n/216 inch
[ESC] 3 <n>
1BH 33H <n>
<27><51><n>
&%SV <m > <m ><m
1 2 3
[ESC] 3 <n>
The [ESC] 3 <n> command sets the default line spacing to n/216 inch. Set n = 1 to
255. The command takes effect immediately and sets the line feed spacing used by
[LF] to values other than 1/8 or 7/72 inch.
Line spacing of n/144 inch is used.
Set line space 27/216 inch
[ESC] 0
1BH 30H
<27><48>
&%ST
[ESC] 2
The [ESC] 0 command sets the default line spacing to 1/8 or 27/216 inch, which is
the standard eight lines per inch line spacing at initial power up.
In EPOS mode, the command sets 1/6-inch spacing or six lines per inch.
>
3

Figure 14 Example of fine line feed

>
Rev Q
Programmer's Guide
11/07/05
