Extended Apa Graphics - TransAct Ithaca 90PLUS Series Programmer's Manual

Printer Control Codes
Graphic Mode
5.9.2

Extended APA Graphics

Function
ASCII
Hexadecimal
Decimal
IPCL
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
Description
Function
ASCII
Hexadecimal
Decimal
IPCL
EPOS
Description
Note
Page 50
PcOS Series 90PLUS
Print graphics in mode <m> (60 h/120 h/240 h x 72 v dpi)
1 2
[ESC] * <m> <n> <n>
1 2
1BH 2AH <m> <n> <n>
1
<27> <42> <m> <n> <n>
none
1
The [ESC] * <m> <n> <n>
listed above as specified by <m>.
Where <m>: 0
1 120 dpi
2 120 dpi
3 240 dpi
4
5
6
7 144 dpi
8, 9, 11, 12, 13, 14, 16
Reassign graphic mode
[ESC] ? <m> <n>
1BH 3FH <m> <n>
<27> <63> <m> <n>
none
The [ESC] ? <m> <n> command reassigns graphic mode, <m>, to resolution,
<n>. Possible values for <m> are K, L, Y, or Z. Resolutions, <n>, are 0 to 7 as
follows:
Where <m>: 0
1 120 dpi
2 120 dpi
3 240 dpi
4
5
6
7 144 dpi
Begin unidirectional print
[ESC] U <1>
1BH 55H 01H
<27> <85> <1>
&%GU
[ESC] U <1>
The [ESC] U <1> command prints all data in unidirectional print mode to
improve line to line registration for graphical data.
The command should be canceled before normal text is printed. It will slow
printing time if it is not canceled.
Rev Q
Programmer's Guide
2
2
command selects one of the three graphic modes
60 dpi full speed
half speed
full speed
full speed
80 dpi full speed
72 dpi full speed
90 dpi full speed
full speed
not supported
60 dpi full speed 8-bit slices
half speed 8-bit slices
full speed 8-bit slices
full speed 8-bit slices
80 dpi full speed 8-bit slices
72 dpi full speed 8-bit slices
90 dpi full speed 8-bit slices
full speed 8-bit slices
8-bit slices
8-bit slices
8-bit slices
8-bit slices
8-bit slices
8-bit slices
8-bit slices
8-bit slices
default for K
default for L
default for Y
default for Z
11/07/05
