pip

Sets or gets the on-screen PIP mode. The PIP feature allows the near site to
adjust near-camera views while in a video conference.
Syntax
pip <get|on|off|auto|camera|swap|register|unregister|location>
pip location <get|0|1|2|3>
Parameter
get
on
off
auto
camera
swap
register
unregister
location
Feedback Examples
• pip on
• pip off
• pip auto
• pip camera
• pip swapped
Description
Returns the current setting.
Enables PIP mode. The VSX system shows a PIP
window that remains in the lower right corner of the
screen until the video call is completed.
Disables PIP mode.
Causes the VSX system to show a PIP window when
the call is first connected and when the remote control
is not resting on a flat surface.
Causes the PIP window to appear when the selected
camera position is changed. The PIP window
disappears when the camera has finished moving.
Toggles the content of the PIP and the main display
between the near-site and far-site view.
Registers the system to give notification when PIP is
turned on or off.
Unregisters the system to give notification when PIP is
turned on or off.
Places the PIP window in the specified corner of the
screen:
0 = bottom right corner
1 = top right corner
2 = top left corner
3 = bottom left corner
get = Returns the current location
