UT-4579 X-Band Up Converter
Installation and Startup
Feature Description
1 Custom Rack Enclosure
2 UT-4579 chassis
3 Standard Rack Shelving
4 Rack Enclosure Threaded Front Rail (typical)
5 Unit Front Panel
6 User-supplied Screws
Figure 3-2. Install the Unit into a Rack Enclosure
3–4
MN/UT4579.IOM
Revision 1
