Clr (Clear Pre-Select Configuration); Sel (Select Pre-Select Configuration); Operating Modes; Red (Redundant Mode) - Comtech EF Data UT-4579 Installation And Operation Manual

DT-4579 X-Band Up Converter
Serial Interface Operation
8.7.3.11

CLR (Clear Pre-select Configuration)

Use CLR to clear a single pre-select value.
Description
Clear a Preset:
Confirmation:
8.7.3.12

SEL (Select Pre-select Configuration)

Use SEL to load a pre-select number configuration.
Description
Select Pre-select:
Confirmation:
8.7.4

Operating Modes

There are two modes of operation that may intersect: Redundant Mode and
Automatic Mode.
8.7.4.1

RED (Redundant Mode)

Each converter, including the backup converter, must be active in the Redundant
Mode. The default mode is OFF.
Description
Redundant Mode:
Confirmation:
Redundant Status:
Confirmation:
1) The primary units must all be configured properly in redundant
mode before you can enable redundant mode on the backup unit.
2) Polling on the high speed bus will not begin until the position
assignments are made.
Details
<DEV/CLR_nn{cr} where:
nn = Pre-select Number (01 to 32)
>DEV/CLR_nn_Cleared{cr}{lf}]
Details
<DEV/SEL_nn{cr} where:
nn = Pre-select Number (01 to 32)
NOTE: Only programmed pre-select numbers are available.
>DEV/SEL_nn_Selected{cr}{lf}]
Details
<DEV/RED_xxx{cr} where:
xxx = ON or OFF
>DEV/RED_xxx{cr}{lf}]
<DEV/RED_{cr}
>DEV/RED_xxx{cr}{lf}]
