Pullout Force; Tools Required - CYBEX PP-ACO Assembly Manual

• Minimum drill depth in concrete:
• Standard fasteners 1/2" beyond anchor length
• Metric fasteners 10mm beyond anchor length
• Minimum concrete embedment:
• KH-EZ 3/8": 3-1/4" (83mm)
• HUS-H 8mm: 75mm (2-3/32")

Pullout Force

Cybex specifies Hilti™ static and dynamic anchors. According to the anchor manufacturer, the recommended
design pullout force (in tension) for the specified anchors, when properly installed in cracked concrete, is provided
in the side table. This table should be used for reference only; for additional and up-to-date information on the
anchor capabilities or the design pullout force in other substrates, please consult Hilti directly at
https://www.us.hilti.com.
Selected Anchor
KH-EZ ¼" x 4"
HUS-H 6MM x 120MM
KH-EZ 3/8" x 4"
KH-EZ 3/8" x 5"
HUS-H 8MM x 120MM
HUS-H 8MM x 150MM
HST M12 x 115/20
HST M12 x 195/200
KB-TZ 3/8" x 3-3/4"
* Design strength extracted from the Hilti Anchor Fastening Technology Manual issued September 2014.

Tools Required

Static Anchor
• Floor scanner/rebar detector (optional)
• 1" L-shape SDS rotary hammer
• 1/4" x 12" (6mm x 305mm) carbide drill bit (for 1/4" (6mm) anchors)
• 3/8" x 12" (8mm x 305mm) carbide drill bit (for 3/8" (8mm) anchors)
• Safety glasses
• Extension cord
• Impact wrench
• Vacuum (for debris)
HSL-3/8 4"
Adhere to manufacturer's equipment warnings and guidelines. Follow manufacturer's
instructions for proper usage.
Design Resistance in Tension *
