Install Storage Connector - CYBEX PP-ACO Assembly Manual

Install Storage Connector

The following procedure shows how to install the Storage Connector (SX) to the CORE.
Tools Required:
• 7 mm Allen wrench (x2)
• 17 mm Open end wrench
• Torque wrench
Note: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
2.
1 Screw, M10 x 1.5, 65 mm
2
3
4
5
1 Screw, M10 x 1.5, 130 mm
2
3
4 Nut, M10 x 1.5 socket head
5
Page 25 of 54
Description
Washer
Nut, hex nylock
Bracket
Storage connector
Description
Washer
Spacer
Storage connector
Qty
2
2
2
1
1
Qty
2
2
2
2
1
