Install Storage Station - CYBEX PP-ACO Assembly Manual

Install Storage Station

The following procedure shows how to install the Storage Station (SC) to the CORE.
Tools Required:
• 7 mm Allen wrench (x2)
• 17 mm Open end wrench
• Torque wrench
Note: All screws must be torqued to 25-30 FT-LBS. (27.1-33.9Nm).
1.
2.
3.
1 Screw, M10 x 1.5, 25 mm
2
3
4
5
1 Screw, M10 x 1.5, 65 mm
2
3
4
1 Screw, M10 x 1.5, 80 mm
2
3 Nut, M10 x 1.5 socket head
4
5
Page 26 of 54
Description
Washer
Nut, hex nylock
Top mount
Core
Description
Nut, hex nylock
Washer
Hanger
Description
Washer
Bracket
Storage station
Qty
3
3
3
1
1
Qty
2
2
2
1
Qty
4
4
4
1
1
