VR1
Row/Rear Delt
Owner's Manual
Part Number
13030-999-4 AC

Advertisement

Table of Contents
loading

Summary of Contents for CYBEX VR1 Row/Rear Delt

  • Page 1 ® Row/Rear Delt Owner's Manual Part Number 13030-999-4 AC...
  • Page 3: Table Of Contents

    Cybex International, Inc. DISCLAIMER: Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
  • Page 4: Safety Guidelines And Practices

    • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
  • Page 5: User Safety Precautions

    • DO NOT pin weights on selectorized equipment in an elevated position or use the machine if found in this position • DO NOT increase weight resistance on equipment by any means other than those provided by Cybex. • DO NOT wear loose or dangling clothing or jewelry while using equipment. Stay clear of moving parts.
  • Page 6: Label Placement

    Label Placement The following diagram shows where each label is located. Page 6 of 23...
  • Page 7 Description DE000001-X DE000005-X 4520-362-X 8500-025-X Page 7 of 23...
  • Page 8: Assembly

    Assembly Machine Specifications Total Weight and Size VR1 Row/Rear Delt 13030 Standard Stack Weight Machine Dimensions at Rest Machine Dimensions in Use 493 Lbs 46” L × 47” W × 76” H Same 224 Kg 116 cm L × 119 cm W × 193 cm H...
  • Page 9: Verify Parts List Below

    Climatic dry air may cause static electricity. During workout, user may experience a shock due to build up of static electricity on the body and the discharge path of the unit. If static electricity is experienced, increase humidity to a comfortable level through the use of a humidifier. Do not install, use or store the unit in an area of high humidity, such as in the vicinity of a steam room, sauna, indoor pool or outdoors.
  • Page 10: Tools Required

    • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
  • Page 11 Description Qty. BHSCS Top cap Shroud 2. Remove top cap and BHSCS. 3. Lift shroud up and out of machine. 4. Remove guide rod caps. Guide rod cap contains a compression spring that will fly if grasp is not released slowly.
  • Page 12 8. Remove lifting post. 9. Remove weight plates. 10. Move to desired location. 11. Remove shipping cones using a 3/4” socket or wrench. Remove bolt from shipping cone with hammer. Recycle cone. 13. Attach foot pads to each foot of frame. Install weight plates 1.
  • Page 13 Description Backing Front sheet Weight decals 2. Place decals front sheet in the correct position on weight plates. 3. Insert a guide pin through each hole of the decals front sheet. A guide pin can be anything that fits through the weight stack hole, such as a weight stack selector pin.
  • Page 14 • Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
  • Page 15: Exercise

    Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions TIP: Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual. CAUTION: Use only in manner depicted.
  • Page 16: Maintenance

    Cybex International, Inc. is not responsible for performing regular inspection and maintenance actions for your machines. Instruct all personnel in equipment inspection and maintenance actions and also in accident reporting and recording. Cybex International, Inc. representatives are available to answer any questions that you may have. Warnings TIP: Read all warnings in this chapter.
  • Page 17: Weekly Procedures

    Then Dampen a soft white cloth with rubbing alcohol. More Difficult Stains Gently rub stained area. (Alternative Method) Dampen a clean soft cloth in water and rinse area. Apply a light coat of furniture wax for 30 seconds. Restoring Luster Lightly rub area using a clean white cloth.
  • Page 18: Yearly Procedures

    • Hammer • 3/16” Pin punch Four types of cable tension adjustment are used on Cybex Strength Systems: Jam Nut Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at the cable cam end as the primary adjustment.
  • Page 19 Description Qty. Jam nut Tension adjustment nut Rod End Adjustment This type of adjustment uses a socket head cap screw (SHCS) securing a cable rod end bearing to the machine. Primary adjustment is by turning the rod end bearing. The other end of the cable usually contains a roll pin cable adjustment.
  • Page 20 Description Qty. Cam bolt adjustment Page 20 of 23...
  • Page 21: Customer Service

    To speak with a customer service representative, call 800-351-3737 (for customers living within the USA) or 847-288-3700 (for customers outside the USA). The following information located on the serial number decal will assist our Cybex representatives in serving you. • Unit Serial Number, Product Name and Model Number •...
  • Page 22: Damaged Parts

    At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label. The ARS label and the RMA numbers must be clearly displayed on the outside of the package that contains the item(s) to be returned.
  • Page 24 Columbia Center III - 9525 West Bryn Mawr Ave, Rosemont, IL 60018 • 800-351-3737 • 847-288-3700 • FAX 800-216-8893 www.cybexintl.com...
