3. Locate the antistatic wrist strap shipped with the chassis. Attach the antistatic wrist strap to
your wrist and plug the cable from the antistatic wrist strap into the ESD grounding receptacle
at the upper right corner of the chassis.
4. Remove the module from the plastic bag. (Save the bag in the event the module must be
reshipped.) Observe all precautions to prevent damage from Electrostatic Discharge (ESD).
5. Examine the module for damage. If any damage exists, DO NOT install the module.
Immediately contact Enterasys Networks. Refer to "Getting Help" on page xv.

Installation

To install the module, refer to Figure
Caution: To prevent damaging the backplane connectors in the following step, take care that the
module slides in straight and properly engages the backplane connectors.
Ensure that the top lever lines up with the desired slot number located on the front panel of the
chassis. Refer to
Precaución: Para evitar que se dañen los conectores del panel posterior en el siguiente paso,
intente deslizar el módulo en forma recta y verifique que se enganche correctamente en los
conectores de panel posterior.
Asegúrese de que la palanca superior esté alineada con respecto al número de ranura
correspondiente ubicado en el panel frontal del chasis. Consulte en
1. Locate the chassis card guides that line up with the slot number in which the module will be
installed. Make sure the module locking levers are in the open position (top and bottom).
2. Align the module card between the upper and lower card guides of the desired slot and slide
it into the chassis, taking care that the module slides in straight. See Caution below.
Caution: Due to the amount of force needed to properly seat the module connectors into the
backplane connectors, it is best to apply force to the end of the levers to insert (or eject) the module.
Otherwise, damage could result to the module and chassis.
Precaución: Para colocar los conectores del módulo en los conectores del panel posterior
correctamente es necesario hacer bastante fuerza, por ello, para insertar o quitar el módulo, se
recomienda concentrar la fuerza en el extremo de las palancas. Si no lo hace, podría dañar el
módulo y el chasis.
3. Slide the module into the slot until you can engage the top and bottom locking levers.
Caution: In step 4, do not force the locking levers to the point that they touch the face of the front
panel. Forcing the locking levers to this point could damage the module and chassis.
Precaución: En el paso 4, tenga cuidado de no llevar las palancas de cierre a un punto en donde
estén en contacto con el panel frontal. Si lo hace, podría dañar el módulo y/o el chasis.
4. Refer to the Caution note above, then rotate the two levers into the closed position.
5. If the chassis in which the module is installed was powered down for the installation, turn the
power supplies on. Check to see that the module CPU LED settles at solid green after a few
minutes. If the LED does not turn solid green, refer to Chapter
3‐6 and proceed as follows:
Figure 3-6.
Installing Module into Matrix E7 or N7 Chassis
Figure 3-6
4 for troubleshooting details.
Matrix DFE-Diamond Series Installation Guide 3-11
.
