Gigabit Ethernet Specifications

MGBIC-LC03 Specifications (1000BASE-SX)

Table A-5 MGBIC-LC03 Optical Specifications
Item
Transmit Power (minimum)
Transmit Power (maximum)
Receive Sensitivity
Link Power Budget
1. The maximum drive distance (up to 2 km) depends on the quality of the installed multimode fiber-optic cable
segment. Use the Link Power Budget to calculate the maximum cable length of the attached segment. The
Link Power Budget must not exceed those specified in this table. The MGBIC-LC03 input power must not
exceed -3 dBm. Otherwise, saturation could occur.
Table A-6 MGBIC-LC03 Operating Range
Item
62.5 µm MMF
50 µm MMF

MGBIC-LC09 Specifications (1000BASE-LX)

Table A-7 MGBIC-LC09 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Link Power Budget
Table A-8 MGBIC-LC09 Operating Range
Item
62.5 µm MMF
50 µm MMF
50 µm MMF
10 µm SMF
A-4 Specifications
62.5/125 µm MMF
-9.5 dBm
-3 dBm
-20 dBm
1
(Multimode Only) 10.5 dBm
Modal Bandwidth @ 1310 nm
160 MHz/km
400 MHz/km
62.5 µm MMF
-11.5 dBm
-20 dBm
8.5 dBm
Modal Bandwidth @ 1300 nm
500 MHz/km
400 MHz/km
500 MHz/km
N/A
50/125 µm MMF
-9.5 dBm
-3 dBm
-20 dBm
10.5 dBm
Range
2,000 Meters
2,000 Meters
50 µm MMF 10 µm MMF
-11.5 dBm -9.5 dBm
-20 dBm -20 dBm
8.5 dBm 10.5 dBm
Range
2-550 Meters
2-550 Meters
2-550 Meters
2-10,000 Meters
