Installing an Optional XENPAK Module

Installing an Optional XENPAK Module

This section describes how to install a XENPAK module into the 7KR4290‐02 DFE module. For the
XENPAK specifications, refer to Appendix
Preparation
Before installing the XENPAK module, proceed as follows:
1. Attach the antistatic wrist strap (refer to the instructions in the antistatic wrist strap package)
before removing the XENPAK module from the antistatic packaging.
2. Remove the XENPAK module from the packaging.
Installation
To install a XENPAK module, refer to Figure
1. Hold the XENPAK module with the top side facing up (as shown in Figure
connector facing the port slot.
2. Carefully align the XENPAK module with the port slot.
3. Push the XENPAK module into the 7KR4290‐02 port slot until the back of the XENPAK
module faceplate is flush against the 7KR4290‐02 front panel.
4. Turn the two thumbscrews clockwise and tighten to secure the XENPAK module to the front
panel. This completes the XENPAK module installation.
3-6 Installation
Caution: Carefully follow the instructions in this manual to avoid damaging the XENPAK module
and 7KR4290-02.
The XENPAK module and 7KR4290-02
strap and observe all static precautions during this procedure. Failure to do so could result in
damage to the XENPAK module and 7KR4290-02. Always leave the XENPAK module in the
antistatic bag or an equivalent antistatic container when not installed.
Precaución: Siga las instrucciones del manual para no dañar el XENPAK ni el módulo
7KR4290-02, puesto que son muy sensible a las descargas de electricidad estática. Utilice la
pulsera antiestática y tome todas las precauciones necesarias durante este procedimiento. Si no lo
hace, podría dañar el XENPAK ni el módulo 7KR4290-02. Mientras no esté instalado, mantenga el
XENPAK en su bolsa antiestática o en cualquier otro recipiente antiestático.
A.
are sensitive to static discharges. Use an antistatic wrist
3‐4 and proceed as follows:
3‐4) and its edge
