Summary of Contents for Konica Minolta bizhub 360

  • Page 3 After reading the manual, store it in the designated holder so that it can easily be referred to when questions or problems arise during operation. The illustrations used in this manual may appear slightly different from views of the actual equipment. bizhub 360...

  • Page 4: Introduction

    The time period for the Sleep function can be set for 1 to 240 minutes in 1 minute increments. Automatic Duplex Copying To reduce paper consumption, use this function to make double-sided (du- plex) copies, automatically. We recommend that you utilize the Low Power function, Sleep function, and Automatic Duplex Copying function. bizhub 360...

  • Page 5: Trademarks And Registered Trademarks

    Introduction Trademarks and Registered Trademarks KONICA MINOLTA, KONICA MINOLTA Logo, and The essentials of imaging are registered trademarks or trademarks of KONICA MINOLTA HOLDINGS, INC. PageScope and bizhub PRO are registered trademarks or trademarks of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

  • Page 6: Table Of Contents

    Checking the copy settings ............x-26 Interrupting a copy job ..............x-26 Programming copy settings ............x-26 Displaying explanations of functions and settings .......x-26 Managing jobs ................x-27 Enlarging the size of text in touch panel screens ......x-27 Explanation of Manual Conventions ..........x-28 bizhub 360...
  • Page 7 Ozone Release ................1-12 Acoustic noise (For European Users Only) ........1-12 Caution Notations and Labels ............1-13 Space Requirements ..............1-15 Operation Precautions ..............1-17 Power Source ................1-17 Operating Environment ..............1-17 Storage of Copies ................ 1-17 bizhub 360...
  • Page 8 To load paper in tray 3 ..............2-53 To load paper into a large capacity unit ........2-56 To load paper into the bypass tray ..........2-58 Incompatible Copy Settings ............2-64 To give priority to the copy setting specified following the first setting ..2-64 bizhub 360...
  • Page 9 Separate Scan Setting ..............3-58 To use Separate Scan mode ............3-58 3.10 Setting Job During Warmup ............3-62 To scan the original during warmup ..........3-62 3.11 Next Job Reservation ..............3-64 To reserve a copy job ..............3-64 bizhub 360...
  • Page 10 To copy using Cover Mode ............5-8 Adding Insertions (Insert Sheet) .............5-12 Function overview .................5-12 To copy using Insert Sheet ............5-14 Inserting Different Original Images into Printed Sets (Insert Image) ..5-20 Function overview .................5-20 To copy using Insert Image ............5-21 bizhub 360...
  • Page 11 To copy using Erase ..............5-75 5.13.2 Erasing Black Marks along Center Fold (Center Erase) ....5-78 To copy using Center Erase ............5-78 5.13.3 Erasing Outside Area of Original (Non-Image Area Erase) ... 5-80 To copy using Non-Image Area Erase ......... 5-80 bizhub 360...
  • Page 12 Function overview ................6-7 To specify finisher output mode .............6-8 Stapling Output Copies (Staple) .............6-10 Function overview .................6-10 To copy using Staple mode ............6-12 Punching File Holes in Copies (Punch) ..........6-15 Function overview .................6-15 To copy using Punch mode ............6-16 x-10 bizhub 360...
  • Page 13 To specify Sound Setting ............. 7-31 7.6.5 Adjusting the Position of Touch Sensor (Touch Panel Adjustment) .. 7-35 To specify Touch Panel Adjustment ..........7-35 7.6.6 Setting Auto Reset Notification (Auto Reset Notification) .... 7-38 To specify Auto Reset Notification ..........7-38 bizhub 360 x-11...
  • Page 14 Paper Tray and Equipment .............9-2 Paper Weight ..................9-3 Paper Tray/ Output Tray Capacity ..........9-4 Paper Capacity in Finisher FS-510 Output Trays ......9-5 Paper Size ..................9-8 Auto Tray Switch Function ..............9-9 Special Paper ................9-10 Precautions for Paper ..............9-12 Paper Storage ................9-12 x-12 bizhub 360...
  • Page 15 Cleaning the left partition glass ............ 12-2 Cleaning the original glass ............12-2 Cleaning the document pad ............12-3 Cleaning the paper take-up roller ..........12-3 Cleaning the writing unit glass and the electrode wires ....12-4 Cleaning the main unit ..............12-4 bizhub 360 x-13...
  • Page 16 3 Paper Tray Setting > 2 Auto Tray Select Setting .....14-12 To specify Auto Tray Select Setting ..........14-12 14.2.5 3 Paper Tray Setting > 3 Auto Tray Switch ON/OFF ....14-14 To specify Auto Tray Switch ON/OFF .........14-14 x-14 bizhub 360...
  • Page 17 How to access the Administrator Setting Screen ......15-2 How to use [Close], [Exit], and layer keys ........15-3 15.1.1 Chart of Setting Items on Utility Screens ........15-4 Administrator Security Level ............15-4 Marks and indication in the chart ..........15-4 bizhub 360 x-15...
  • Page 18 To specify Original Image Density ..........15-54 15.2.16 7 Expert Adjustment>2 Erase Adjustment ........15-56 To specify Erase Adjustment ............15-56 15.2.17 7 Expert Adjustment>3 Finisher Adjustment ......15-59 To specify Finisher Adjustment ...........15-59 15.2.18 8 List/Counter>1 Management List ..........15-65 To specify Management List ............15-65 x-16 bizhub 360...
  • Page 19 To specify Print without Authentication ........15-109 15.4.8 5 Counter List ................15-111 To specify Counter List ............15-111 15.5 6 Copier Setting ................15-113 15.5.1 Auto Zoom (Platen) ..............15-113 To specify Auto Zoom (Platen) ..........15-113 bizhub 360 x-17...
  • Page 20 To specify Security Details ............15-127 15.6.4 7 Management Function Setting>3 Network Function Setting 15-130 To specify Network Function Setting ........15-130 16 Appendix 16.1 Entering Text ..................16-2 To type text ...................16-4 List of Available Characters ............16-4 17 Index x-18 bizhub 360...

  • Page 21: Available Features

    For details, refer to “Separate Scan Setting” on page 3-58. bizhub 360 x-19...

  • Page 22: Copying Multiple Original Pages Onto A Single Page

    Inserting paper between copies of overhead projector transparencies After each overhead projector transparency copy is printed, a page can be added to the stack as an interleaf. For details, refer to “Copying onto OHP Transparencies (OHP Interleave)” on page 5-2. x-20 bizhub 360...

  • Page 23: Adding A Cover Page/Insertion

    Copying with chapter title pages on the front side Double-sided copies can be made so that the chapter title pages are printed on the front sides of pages. For details, refer to “Locating Title Pages on Front Side (Chapters)” on page 5-25. bizhub 360 x-21...

  • Page 24: Repeating Copy Images

    A single original page can be divided in two and each half can be printed on separate copies. For details, refer to “Dividing Spread Image into Right and Left Pages using ADF (Booklet Pagination)” on page 5-56. x-22 bizhub 360...

  • Page 25: Copying With A Layout For Center Binding

    5-64. Making copies for filing Copies can be printed with a filing margin so they can easily be stored in filing binders. For details, refer to “Creating Margin of Copy Image (Page Margin)” on page 5-66. bizhub 360 x-23...

  • Page 26: Erasing Sections Of Copies

    For details, refer to “Adjusting Position of Copy Image (Image Adjustment)” on page 5-83. Printing distribution text on copies Each copy set can be printed with distributions numbers, page numbers, or the date. For details, refer to “Printing Additional Information (Stamp/Overlay)” on page 5-88. x-24 bizhub 360...

  • Page 27: Sorting Copies

    For details, refer to “Stapling Output Copies (Staple)” on page 6-10. Punching holes in copies Holes for filing can be punched in the copies. For details, refer to “Punching File Holes in Copies (Punch)” on page 6-15. bizhub 360 x-25...

  • Page 28: Center Folding/Binding

    7-11. Displaying explanations of functions and settings The name and function of parts and details of functions and settings appears in the Help screens. For details, refer to “Displaying Screen for Operation Guide (Help)” on page 7-20. x-26 bizhub 360...

  • Page 29: Managing Jobs

    The text and buttons in the touch panel can be displayed in a larger size that is easier to read, allowing basic copy operations to be easily performed. For details, refer to the Enlarge Display Operations of the bizhub 360 User’s Guide.

  • Page 30: Explanation Of Manual Conventions

    "Warning" indicates instructions that, when not observed, may result in fatal or critical injuries. "Caution" indicates instructions that, when not observed, may result in serious injuries or property damage. (The page shown above is an example only.) x-28 bizhub 360...

  • Page 31: Descriptions And Symbols For Original And Paper

    (X), the paper has a vertical orienta- tion, indicated by w. Crosswise (v) If the width (Y) of the paper is longer than the length (X), the paper has a horizontal orienta- tion, indicated by v. bizhub 360 x-29...

  • Page 32: User's Guides

    User’s Guide [Network Fax Operations] This manual contains details on operating procedures for network faxing. - Refer to this User’s Guide for details on operating procedures for using the network fax functions (Internet Fax/IP Address Fax). x-30 bizhub 360...

  • Page 33: User's Guide [Network Scanner Operations

    - For operating procedures for printer functions, refer to the user’s guide (PDF) contained in User Software CD-ROM or the quick guide (printed material) attached to IC-204. To operate safely, be sure to read “Section 1 Safety Information” in bizhub 360 User’s Guide [Copy Operations] before using machine. bizhub 360 x-31...
  • Page 34 In addition, it is prohibited under any circumstances to copy domestic or for- eign currencies, or works of art without permission of the copyright owner. When in doubt about the nature of a document, consult with legal counsel. x-32 bizhub 360...

  • Page 35: Installation And Operation Precautions

    Installation and Operation Precautions...

  • Page 36: Safety Information

    This symbol warns against cause burns. A diagonal line indicates a prohibited course of action. This symbol warns against dismantling the device. A solid circle indicates an imperative course of action. This symbol indicates you must unplug the device. bizhub 360...
  • Page 37 Should any of these conditions be found, im- mediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative. bizhub 360...
  • Page 38 Overload could result in a fire. CAUTION • The outlet must be near the equipment and easily accessible. Otherwise you can not pull out the power plug when an emergency occurs. bizhub 360...
  • Page 39 Dust that accumu- lates between the plug terminals may cause a fire. Grounding WARNING • Connect the power cord to an electrical outlet that is equipped with a grounding terminal. bizhub 360...
  • Page 40 • Do not let any object plug the ventilation holes of this product. Heat could accumulate inside the product, resulting in a fire or malfunction. • Do not use flammable sprays, liquids, or gases near this product, as a fire could result. bizhub 360...
  • Page 41 When checking the inside of the unit for mal- functions such as a paper misfeed, do not touch the locations (around the fusing unit, etc.) which are indicated by a “Caution HOT” cau- tion label. bizhub 360...
  • Page 42 If the unit falls it may cause severe personal injury. The product may also be damaged or malfunction. Before successive holidays CAUTION • Unplug the product when you will not use the product for long periods of time. bizhub 360...

  • Page 43: Regulation Notices

    FCC rules. INTERFERENCE-CAUSING EQUIPMENT STANDARD (ICES-003 ISSUE 4) (For Canada Users) This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. bizhub 360...

  • Page 44: For Users In Countries Not Subject To Class B Regulations

    Tämä on puolijohdelaser. Laserdiodin suurin teho on 10 mW ja aallonpituus on 775 - 800 nm. VARNING! Om apparaten används på annat sätt än I denna bruksanvisning specificer- ats, kan användaren utsättas för osynlig laserstrålning, som överskrider 1-10 bizhub 360...
  • Page 45 Installation and Operation Precautions gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 10 mW och våglängden är 775 - 800 nm. bizhub 360 1-11...

  • Page 46: Ozone Release

    Acoustic noise (For European Users Only) Maschinenlärminformations-Verordnung 3. GPSGV: Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäss EN ISO 7779. 1-12 bizhub 360...

  • Page 47: Caution Notations And Labels

    NOT TOUCH. CAUTION This area generates high voltage. If touched, electrical shock may occur. DO NOT TOUCH! CAUTION The area opened by the Finisher FS-510 conveyance lever is very hot. To avoid getting burned DO NOT TOUCH. bizhub 360 1-13...
  • Page 48 Be sure to hold both sides of the printed sheets when removing them, and DO NOT leave your hand on the printed sheets while the tray 2 (primary tray) goes up. Finisher FS-511 1-14 bizhub 360...

  • Page 49: Space Requirements

    (200) 21.7 25.7 23.2 27.9 26.7 (550) (708) (652) (677) (590) 64.5 (1637) 53.1 (1350) 15.6 45.3 (397) (1150) 20.8 (530) 25.3 (642) 79.5 57.4 (2019) (1458) bizhub 360 + PC-202 + FS-510 + SD-502 + LU-201 bizhub 360 1-15...
  • Page 50 (708) 64.5 (1637) 56.1 (1425) 15.6 (397) (1245) 16.5 (418) 57.4 78.1 (1985) (1458) bizhub 360 + PC-202 + FS-510 + MT-501 + LU-201 Unit : Inch (mm) (100) (100) (200) 35.8 26.7 23.2 21.7 27.9 19.2 (910) (677) (590)

  • Page 51: Operation Precautions

    - Copies that are to be kept for a long time should be kept where they are not exposed to light in order to prevent them from fading. - Adhesive that contains solvent (e.g., spray glue) may dissolve the toner on copies. bizhub 360 1-17...

  • Page 53: Before Making Copies

    Before Making Copies...

  • Page 54: Machine Configuration

    Before Making Copies Before Making Copies Machine Configuration External Name Description Left partition glass Scans the original positioned in the ADF. Document scales Used to align the document. Document pad Presses down on the document positioned on the original glass. bizhub 360...
  • Page 55 Front door Opened when replacing the toner cartridge, or cleaning the writing unit glass or corona wire. Refer to page 10-3 and page 12-4, for details. Paper output tray Collects printed pages. bizhub 360...
  • Page 56 Before Making Copies bizhub 360...
  • Page 57 Used for connecting to a computer via a USB cable. 1.1-compliant Network connector (10 Base- Used for connecting to the network cable for a local net- T/100 Base-TX) work when this machine is used for network printing and network scanning. bizhub 360...

  • Page 58: Internal

    Before Making Copies Internal bizhub 360...
  • Page 59 Opened to pull out the toner cartridge holder when re- placing the toner cartridge. Corona wire cleaning lever Pull out when cleaning the corona wire. Writing unit glass cleaning le- Pull out when cleaning the writing unit glass. Main power switch Used for turning on/off the machine. bizhub 360...

  • Page 60: Options

    Consists of 2 trays, each of which can be loaded with up to 500 sheets of paper (20 lb). Paper Feed Cabinet PC-402 Can be loaded with up to 2,500 sheets of paper (20 lb). Relay Unit RU-502 Relays paper between the main unit and finisher FS-511. bizhub 360...
  • Page 61 Stamp Unit SP-501 Installed onto ADF.Stamps scanned document pages to indicate that they have been faxed. Security Kit SC-502 Installed to encode the data saved on the hard disk so that the hard disk can be used more safely. bizhub 360...
  • Page 62 Before Making Copies Paper Feed Cabinet PC-202/PC-402 2-10 bizhub 360...
  • Page 63 A maximum of 2,500 sheets of plain paper (20 lb) can be loaded. Cabinet lock release button Pressed in order to pull out the paper feed cabinet. Paper limit indication (,) Indicates the maximum amount of paper to be loaded. bizhub 360 2-11...

  • Page 64: Large Capacity Unit Lu-201

    Before Making Copies Large Capacity Unit LU-201 Reminder Do not climb on, or place objects on this unit to prevent any damage. 2-12 bizhub 360...
  • Page 65 Held to slide the large capacity unit to the right when clearing paper misfeeds. Paper take-up roller Feeds one sheet of paper at a time into the main unit. Paper limit indication (,) Indicates the maximum amount of paper to be loaded. bizhub 360 2-13...

  • Page 66: Finisher Fs-510/Output Tray Ot-601/Punch Unit Pu-501

    Before Making Copies Finisher FS-510/Output Tray OT-601/Punch Unit PU-501 Reminder Do not place objects beneath the output tray to prevent any damage in- curred by shock or other forces. 2-14 bizhub 360...
  • Page 67 Stores staples. Pulled out from the stapler when loading staples or clearing paper misfeeds. Dial Turned to move the stapler to the front when clearing jammed staples or loading staples. Guide (FN5) Rotated when clearing paper misfeeds. Guide (FN6) Rotated when clearing paper misfeeds. bizhub 360 2-15...

  • Page 68: Saddle Stitcher Sd-502/Mailbin Kit Mt-501

    Make sure that there is no object on or beneath the finisher. Do not place objects on, or lean against, the saddle stitcher or mailbin to prevent any damage. 2-16 bizhub 360...
  • Page 69 Pulled to slide to the left when clearing paper misfeeds. Mailbin Kit MT-501 Name Description Lower cover lever Pulled down to open when clearing paper misfeeds. Mailbins Collects printed and sorted sheets. Misfeed-clearing door Pulled to the right to open when clearing paper misfeeds. bizhub 360 2-17...

  • Page 70: Finisher Fs-511/Relay Unit Ru-502

    Before Making Copies Finisher FS-511/Relay Unit RU-502 2-18 bizhub 360...
  • Page 71 Staple cartridge holder Stores staples.Pulled out from the stapler when loading staples or clearing paper misfeeds. Dial Turned to the left to move the stapler to the center when clearing jammed staples or loading staples. Stapler Staples paper. bizhub 360 2-19...

  • Page 72: Control Panel

    Press to enter the Scan mode. While the machine is in the Scan mode, the indicator on the [Scan] key lights up in green. For details, refer to Network Scanner Operations of the bizhub 360 User's Guide. [Copy] key Press to enter the Copy mode. (This machine is default to the Copy mode.) While the machine is in the Copy mode,...
  • Page 73 Press to switch between the Enlarge Display mode and the standard display mode. Reminder Do not press the touch panel with an object with a sharp end or apply ex- treme pressure to it, otherwise it may be scratched or damage bizhub 360 2-21...

  • Page 74: Basic Screen And Icons

    Displays the Original Image Type Screen to specify the original image settings. [Application] tab Touched to display the Application Screen to specify the application settings. Memory availability display Displays the amount of memory available for operations. area 2-22 bizhub 360...
  • Page 75 For details, refer to the Box Operations of the bizhub 360 User's Guide. (Only availa- ble when Hard Disk HD-505 is installed.) [Separate Scan] Touch to store scanned images in memory.

  • Page 76: Icons Shown In The Icon Display Area

    Indicates that data is being sent from the machine, regardless of the cur- rent mode. Indicates that data is being received by the machine, regardless of the current mode. If the warning screen was closed when a warning occurred, touch this key to display the warning screen again. 2-24 bizhub 360...

  • Page 77: Basic Screen And Icons

    Displays the amount of memory available for operations. area Copying amount display area Displays the number of copies specified. [Background Removal] tab Displays the Background Removal Screen to specify the background adjustment. [Separate Scan] Touch to store scanned images in memory. bizhub 360 2-25...

  • Page 78: Icons Shown In The Icon Display Area

    For details, refer to the Box Operations of the bizhub 360 User's Guide. (Only availa- ble when Hard Disk HD-505 is installed.) [Folding] Touched to specify the Half Fold and Fold &...

  • Page 79: Adjusting Angle Of The Control Panel

    Adjusting Angle of the Control Panel The control panel can be adjusted to any of the following three angles. Adjust the control panel to the angle that allows for easy operation. 1 Upper position (base position) 2 Middle position 3 Lower position bizhub 360 2-27...

  • Page 80: To Adjust The Angle Of The Control Panel

    To adjust the angle of the control panel Pull the control panel release lever toward you to unlock the current po- sition. Move the control panel slightly to any direction, and release the control panel release lever. 2-28 bizhub 360...

  • Page 81: Turning On/Off The Power

    The main power switch is located in- side the machine. – Open the front doors of the main unit, and turn on the main power. The main power indicator on the control panel lights up in green. bizhub 360 2-29...
  • Page 82 For details, refer to page 2-42. The user may also be required to insert a key counter or copy card into the machine. Follow the instructions accordingly. 2-30 bizhub 360...

  • Page 83: Turning Off The Machine

    – Press the sub power switch to turn it off. The display on the touch panel goes off, and all the lights are turned off except for the main power indicator. bizhub 360 2-31...
  • Page 84 Open the front doors of the main unit, and turn off the main power. Reminder When turning off and then turning on the main power, do so with an in- terval of at least 10 seconds between the actions. Otherwise the machine may fail to function correctly. 2-32 bizhub 360...

  • Page 85: Automatically Returning To The Default Settings (Automatic Panel Reset)

    As the factory default, the Copy Mode Screen is displayed after 1 minute. Detail Use the Utility mode to specify the length of time before the automatic system reset is activated, or to give priority to a screen. For details, refer to page 15-69. bizhub 360 2-33...

  • Page 86: To Use Machine When Power Save Indicator Lights

    The power save function has two modes: the Low Power mode and the Sleep mode. For details, refer to page 2-35 to page 2-36. The power save mode can be activated manually. For details, refer to page 2-37. 2-34 bizhub 360...

  • Page 87: Automatically Conserving Energy (Low Power Mode)

    Pressing any key or the surface of the touch panel also re- turns the machine to an operational state. The touch panel display reappears and, after the machine has finished warming up, it is ready to operate again. bizhub 360 2-35...

  • Page 88: Automatically Conserving Energy (Sleep Mode)

    Power mode, it needs to take longer than Low Power mode to warm up when Sleep mode is cancelled before getting ready to print again. The machine can receive jobs even while it is in the Sleep mode. As the factory default, the machine enters the Sleep mode after 15 minutes. 2-36 bizhub 360...

  • Page 89: To Interrupt The Sleep Mode To Activate The Machine

    The length of time before the machine enters Sleep mode can be changed. For details, refer to page 15-25. If the time for entering Low Power mode and Sleep mode are the same, the machine will immediately enter Sleep mode without entering Low Power mode. bizhub 360 2-37...

  • Page 90: Manually Conserving Energy

    As the factory default settings, pressing the [Power Save] key will turn the machine into the Low Power mode. By using the Administrator Settings Screen, this setting can be changed so that it enters the Sleep mode with the same user operation. For details, refer to page 15-25. 2-38 bizhub 360...

  • Page 91: Limiting Machine Usage (Weekly Timer)

    To specify that the password for non-business hours should be entered prior to setting the duration before the machine returns to the sleep mode again, use the Administrator mode. This function is not set as the factory default. For details, refer to page 15-48. bizhub 360 2-39...

  • Page 92: Operating The Machine During Non-Business Hours (Weekly Timer)

    Screen appears. Proceed to Step 2. Enter the password for non-business hours from the keypad. – The password can be specified up to 8 digits. – To correct inputting errors, touch [Delete] and enter the correct password. 2-40 bizhub 360...
  • Page 93 5 minutes.In addition, a minutes set- ting of 60 or more cannot be specified. Reminder If you finish using the machine before the set length of time, you can press and hold the [Power Save] key to apply the Sleep mode. bizhub 360 2-41...

  • Page 94: Making Authentication

    (account track)” section. 0 The machine functions or the amount of printed copies permitted may be specified between different users. Turn on the machine power. The User Name/Password Setting Screen will be displayed. 2-42 bizhub 360...
  • Page 95 If [List] is displayed, the desired user name can be selected from the list of user names. Touch [List] and select the desired user name, then touch [OK]. Proceed to Step 4. Enter the user name, and then touch [OK]. The User Name/Password Setting Screen will be restored. bizhub 360 2-43...
  • Page 96 The Password Input Screen will be displayed. Enter the password, and then touch [OK]. The User Name/Password Setting Screen will be restored. Press [Access] on the control panel. The Basic Screen will be displayed. Make copies using the desired copy settings. 2-44 bizhub 360...

  • Page 97: To Enter An Account Name And Password (Account Track)

    0 Contact your administrator for password information. 0 The amount of printed copies permitted may be specified differently be- tween accounts. bizhub 360 2-45...
  • Page 98 If the Account Password Setting Screen is displayed, proceed to Step 5. Touch [Account Name]. The Account Name Input Screen will be displayed. Enter the account name, and then touch [OK]. The Account Name/Password Setting Screen will be restored. 2-46 bizhub 360...
  • Page 99 Before Making Copies Touch [Password]. The Account Password Input Screen will be displayed. Enter the password, and then touch [OK]. Press [Access] on the control panel. The Basic Screen will be displayed. Make copies using the desired copy settings. bizhub 360 2-47...
  • Page 100 When you have finished operating the machine, press [Access] on the control panel again. A message appears, requesting confirmation to log off. Touch [Yes]. The Account Name/Password Setting Screen is displayed, indicating that the machine is no longer operational. 2-48 bizhub 360...

  • Page 101: Loading Paper

    Checking the Amount of Paper Remaining in the Tray The Paper Screen is displayed before paper runs out from the tray. The icon beside the tray key indicates the current amount of paper remaining in the tray. bizhub 360 2-49...

  • Page 102: To Load Paper In Tray 1/2 (Or Tray 3/4)

    To load paper in tray 1/2 (or tray 3/4) Follow the procedure described below to load paper into the tray 1/2 or into the tray 3/4 (optional paper feed cabinet PC-202). Pull out the paper tray to be loaded with paper. 2-50 bizhub 360...
  • Page 103 Load the paper into the tray. – Load the paper so that the right side edge is aligned with the right side lining of the tray. bizhub 360 2-51...
  • Page 104 Fully push in the paper tray. The previously displayed red indicator in the pa- per-empty indicator on the right-hand side of the tray disappears. 2-52 bizhub 360...

  • Page 105: To Load Paper In Tray 3

    0 The paper feed cabinet cannot be pulled out when the machine is in the sleep mode. Make sure to interrupt the sleep mode when loading paper into the paper feed cabinet. Press the cabinet lock release button. The cabinet becomes unlocked and is pushed out slightly to the fore. bizhub 360 2-53...
  • Page 106 Load paper into the right side of the cabinet. – Position 8-1/2 × 11 paper in the portrait orientation (v) and align it with the right side lining of the cab- inet. 2-54 bizhub 360...
  • Page 107 Position 8-1/2 × 11 paper in the portrait orientation (v) and align it with the two partitions in the cent- er of the cabinet di- viding the left and right positions. Fully push in the paper feed cabinet. bizhub 360 2-55...

  • Page 108: To Load Paper Into A Large Capacity Unit

    0 A large capacity unit can be loaded with up to 2,000 sheets (20 lb paper) of 8-1/2 × 11-sized paper only. Open the upper door of the large capacity unit, and raise the paper take-up roller. 2-56 bizhub 360...
  • Page 109 Make sure that the paper is not loaded above the point where the paper guide starts to bend to prevent any trouble. Flatten the paper before loading it to prevent any trouble. Do not climb onto the upper door of the large capacity tray to prevent any trouble. bizhub 360 2-57...

  • Page 110: To Load Paper Into The Bypass Tray

    0 Some types of special paper requires to be positioned in a certain orien- taion. For details, refer to pages 2-57 to 2-60. Open the bypass tray. – When loading large- sized paper, pull out the tray extension. 2-58 bizhub 360...
  • Page 111 Paper Screen is displayed. If the type and size of the paper is not identified automatically, manually specify the size. – For details on the paper types and sizes, refer to the section on page 3-20. bizhub 360 2-59...
  • Page 112 Flatten the paper before loading it to prevent any trouble. Load overhead projector transparencies, label sheet or trace paper one sheet at a time. Reminder Load overhead projector transparencies one sheet at a time. 2-60 bizhub 360...
  • Page 113 If the envelopes are loaded with the flap side down, a paper misfeed may occur. The edge with the flap should be positioned toward the rear or left side of the machine. The flap side of envelopes cannot be printed on. bizhub 360 2-61...
  • Page 114 A maximum of 10 sheets of envelopes can be loaded. Flap on the rear side Flap on the left side Reminder Load labels with the printable surface facing down. Load one sheet at a time. For details of the setting orientation, consult your service representative. 2-62 bizhub 360...
  • Page 115 Before Making Copies Reminder Load letterheads with the printable surface facing up. A maximum of 150 sheets of letterheads can be loaded bizhub 360 2-63...

  • Page 116: Incompatible Copy Settings

    Select the 2 Position Staple setting. Set the Booklet function. The first 2 Position Staple setting is automatically cancelled, and the second Booklet function becomes effective. To enable the 2 Position Staple setting instead, cancel the Booklet function. 2-64 bizhub 360...

  • Page 117: To Give Priority To The Copy Setting Specified First

    Select the 2 Position Staple setting. The message “This mode is not available with Booklet” appears and the 2 Position Staple setting cannot be selected. To enable the 2 Position Staple setting instead, cancel the Booklet function. bizhub 360 2-65...

  • Page 119: Basic Copy Operations

    Basic Copy Operations...

  • Page 120: General Copy Operation

    Press [Copy] on the control panel to display the Basic Screen in Copy mode. – The following type of Basic Screen will be displayed as factory de- fault. – The left side area of the screen can also provide the current job list. See page 14-20 for details. bizhub 360...
  • Page 121 Basic Copy Operations Position the original. bizhub 360...
  • Page 122 For details on entering print quantity, see “Setting Print Quantity” on page 3-12. – Print quantity can be entered in any instance of the procedure un- less the control panel keypad is temporarily used for entering other values. Entered quantity will be displayed on the touch panel. bizhub 360...
  • Page 123 Application: page 5-2 Finishing: page 6-2 Folding: page 6-19 Press [Start] on the control panel. – When the machine starts scanning the original, the basic job set- tings and current original count will be displayed on the touch pan- bizhub 360...
  • Page 124 When print operation of the current job is started, scanning for the next job becomes available. For details, see “Next Job Reservation” on page 3-64. To stop the machine operation, press [Stop] on the control panel. For details, see “To Stop/Resume/Delete a Job” on page 3-67. bizhub 360...

  • Page 125: Positioning The Original

    0 Do not load more than 80 sheets of the original or over the limit mark, oth- erwise the original may be misfed or damaged, or machine trouble may be caused. If the number of original sheets exceeds 80, divide them into blocks to scan. For details, see “Separate Scan Setting” on page 3-58. bizhub 360...
  • Page 126 Adjust paper guides. The original size will be detected automatically and displayed in the message area of the Basic Screen, while an appropriate paper size will be selected automatically by Auto Paper Select and displayed in the Paper area. bizhub 360...

  • Page 127: To Position The Original On Original Glass

    0 For the original of thick books or solid objects, start scanning with the ADF kept open. In this case, a bright light may beam through the glass. Be careful not to look directly at the original glass. Raise the ADF. Position the original FACE DOWN on the original glass. bizhub 360...
  • Page 128 3-10 bizhub 360...
  • Page 129 Centering or Non-Image Area Erase is selected, the ADF should not be closed while all the originals are scanned. In this case, be sure to manually select the desired paper size, as the ma- chine cannot detect the original size automatically. bizhub 360 3-11...

  • Page 130: Setting Print Quantity

    0 Print quantity can be entered in any instance of the procedure unless the control panel keypad is temporarily used for entering other values. Enter the desired print quantity from the control panel keypad. Entered quantity will be displayed on the touch panel. 3-12 bizhub 360...

  • Page 131: To Change Print Quantity

    Press [C] (Clear) on the control panel. The quantity displayed on the touch panel will return to 1. Enter the correct quantity from the control panel keypad. Newly entered quantity will be displayed on the touch panel. bizhub 360 3-13...

  • Page 132: Density Setting

    For details, see “Making Copy Quality Closer to Original (Original Image Type)” on page 4-20. To adjust Density/Background Removal Touch [Density] on the Basic Screen. The Density Screen will be displayed. 3-14 bizhub 360...
  • Page 133 Touch [OK] on the Density Screen. The Basic Screen will be restored. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-15...

  • Page 134: Paper Size Setting

    Select. Use this setting for loading special paper in a tray. See page 14-10 for details of “Paper Type”, and see page 3-20 for details of “Paper Setting for Bypass Tray”. Touch [Paper] on the Basic Screen. The Paper Screen will be displayed. 3-16 bizhub 360...
  • Page 135 The Basic Screen will be restored with Auto Paper Select displayed on the Paper key. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-17...

  • Page 136: To Select Paper Size Manually

    Touch the desired tray key to highlight it. – On the tray keys are indicated the size and orientation of the loaded paper. If the tray is specified as Exclusive, the Exclusive icon is also displayed. Touch [OK]. 3-18 bizhub 360...
  • Page 137 See page 15-113 for details. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-19...

  • Page 138: Paper Setting For Bypass Tray

    0 Standard sizes available for Auto Detect in bypass tray: 11×17 w, 8-1/ 2×14 w, 8-1/2×11 w/ v, 5-1/2×8-1/2 v, A4 w 0 Auto Detect is initially set for the bypass tray. Touch [Paper] on the Basic Screen. The Paper Screen will be displayed. 3-20 bizhub 360...
  • Page 139 Touch the bypass tray key to highlight it, then touch [Change Tray Set- tings]. The Change Tray Settings Screen will be displayed. Touch [Auto Detect] to highlight it. Touch [OK] twice. The Basic Screen will be restored. bizhub 360 3-21...

  • Page 140: To Specify/Recall Non-Standard Size (Custom Size)

    “To store non-standard size (Custom Size)” on page 3-24. Touch [Paper] on the Basic Screen. The Paper Screen will be displayed. Touch the bypass tray key to highlight it, then touch [Change Tray Set- tings]. The Change Tray Settings Screen will be displayed. 3-22 bizhub 360...
  • Page 141 What should be done if the message “Input Error” is displayed and entered size cannot be stored? The value just entered is out of available range. % Press [C] (Clear) on the control panel, then reenter the correct value. bizhub 360 3-23...

  • Page 142: To Store Non-Standard Size (Custom Size)

    Side X: 5-13/16 - 17 inch Side X: 3-5/8 - 11-11/16 inch 0 To recall the stored non-standard size, see “To specify/recall non-stand- ard size (Custom Size)” on page 3-22. Touch [Paper] on the Basic Screen. The Paper Screen will be displayed. 3-24 bizhub 360...
  • Page 143 Check that [X] is highlighted, then enter the size of side X from the control panel keypad. (5-13/16 - 17 inch) – Touch [Y] to highlight it, then enter the size of side Y from the con- trol panel keypad. (3-5/8 - 11-11/16 inch) bizhub 360 3-25...
  • Page 144 [OK]. Up to 16 characters can be entered. – The name on the key is not necessary to be changed. Touch [OK] four times. 3-26 bizhub 360...

  • Page 145: To Specify Paper Type

    0 When printing on envelopes, open the right-hand door of the machine and pull up the envelope levers. For details, see page 2-59. 0 The special paper setting of bypass tray will be cleared to the normal type setting, when the machine is reset to the initial setting. bizhub 360 3-27...
  • Page 146 The Change Tray Settings Screen will be displayed. Specify the special paper type. – Touch the desired paper type key to highlight it. – To select Letterhead, Trace, User, Labels, or Colored Paper, touch [Specialty Paper]. 3-28 bizhub 360...
  • Page 147 Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-29...

  • Page 148: Zoom Setting

    0 Use the [+] and [–] keys on the Zoom Screen to make a fine adjustment on specified magnification ratio. Touch [+] to increase, or [–] to decrease the ratio in 0.001 increments. Touch [Zoom] on the Basic Screen. The Zoom Screen will be displayed. 3-30 bizhub 360...

  • Page 149: To Copy In Slightly Reduced Magnification Mode (Minimal)

    0 Use the [+] and [–] keys on the Zoom Screen to make a fine adjustment on the specified magnification ratio. Touch [+] to increase, or [–] to de- crease the ratio in 0.001 increments. Touch [Zoom] on the Basic Screen. bizhub 360 3-31...
  • Page 150 The Basic Screen will be restored with the specified magnification ratio displayed on the Zoom key. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 3-32 bizhub 360...

  • Page 151: To Select A Preset Zoom Ratio

    Touch [+] to increase, or [–] to de- crease the ratio in 0.001 increments. Touch [Zoom] on the Basic Screen. The Zoom Screen will be displayed. Touch the desired preset key to highlight it. bizhub 360 3-33...

  • Page 152: To Specify A Desired Zoom Ratio

    0 Use the [+] and [–] keys on the Zoom Screen to make a fine adjustment on the specified magnification ratio. Touch [+] to increase, or [–] to de- crease the ratio in 0.001 increments. Touch [Zoom] on the Basic Screen. 3-34 bizhub 360...
  • Page 153 Touch [XY Zoom]. The XY Zoom Screen will be displayed. Enter the desired magnification ratio (×0.250 to ×4.000) from the con- trol panel keypad. Entered ratio will be displayed in the Zoom with Constant X and Y Ratio area. bizhub 360 3-35...
  • Page 154 The Basic Screen will be restored with the specified magnification ratio displayed on the Zoom key. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 3-36 bizhub 360...

  • Page 155: To Specify Lengthwise And Widthwise Zoom Ratios Separately (Set Individual Zoom)

    ×0.250 to ×4.000 in ×0.001 in- crements. 0 The Individual Zoom ratio cannot be registered. 0 The [+] and [–] keys on the Zoom Screen cannot be used to make a fine adjustment on the specified Individual Zoom ratio. bizhub 360 3-37...
  • Page 156 Touch the X icon key in the Set Individual Zoom area to highlight it, then enter the desired magnification ratio (×0.250 to ×4.000) from the con- trol panel keypad. Entered ratio will be displayed on the right side of the X icon key. 3-38 bizhub 360...
  • Page 157 Touching [Cancel] will clear the Individual Zoom ratio entered on the XY Zoom Screen. The Zoom Screen will be restored. Touch [OK]. The Basic Screen will be restored with the specified Individual Zoom ratio displayed on the Zoom key. bizhub 360 3-39...

  • Page 158: To Select A Stored Magnification Ratio

    Touch [+] to increase, or [–] to de- crease the ratio in 0.001 increments. Touch [Zoom] on the Basic Screen. The Zoom Screen will be displayed. Touch the desired Set Zoom key to highlight it. 3-40 bizhub 360...

  • Page 159: To Store A Zoom Ratio

    0 The Minimal ratio setting can be changed within the range from ×0.900 to ×0.999. The ratio is set to ×0.930 as factory default. 0 The Individual Zoom ratio cannot be registered. Touch [Zoom] on the Basic Screen. The Zoom Screen will be displayed. bizhub 360 3-41...
  • Page 160 What should be done if the message “Input Error” is displayed and entered size is ignored? The value just entered is out of available range. % Press [C] (Clear) on the control panel, then reenter the correct value. Touch [Set Zoom]. The Set Zoom Screen will be displayed. 3-42 bizhub 360...

  • Page 161: To Select A Magnification Ratio Automatically (Auto Zoom)

    0 The full size (×1.000) mode is initially specified for Zoom as factory de- fault. 0 Auto Zoom and Auto Paper Select are incompatible. For details of Auto Paper Select, see page 3-16. Touch [Zoom] on the Basic Screen. The Zoom Screen will be displayed. bizhub 360 3-43...
  • Page 162 Touch Auto Zoom to highlight it. The Paper Screen will be displayed. Touch the desired tray key to highlight it. Touch [OK]. The Basic Screen will be restored. The appropriate magnification ratio has been selected according to the original size. 3-44 bizhub 360...
  • Page 163 Basic Copy Operations Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-45...

  • Page 164: Simplex/Duplex Setting

    For details, see “Specifying Position of Binding Margin (Margin)” on page 4-17. 0 When selecting 1%2 or 2%2 and making double-sided copies with top margin created (arranged upside down on the reverse side), the binding direction can be specified using the [Binding Direction] key, 3-46 bizhub 360...
  • Page 165 Basic Copy Operations Position the original in the ADF. Touch [Simplex/Duplex] on the Basic Screen. The Simplex/Duplex Screen will be displayed. bizhub 360 3-47...
  • Page 166 Specify the binding direction of original and copy. – The binding direction of original and double-sided copies should be specified manually, otherwise the desired copy result may not be obtained. – Touch [Binding Direction] to display the Binding Direction Screen. 3-48 bizhub 360...
  • Page 167 Touch [OK]. The Basic Screen will be restored. Select additional copy conditions, as desired. – For details on specifying the binding margin for double-sided cop- ies, see “Creating Margin of Copy Image (Page Margin)” on page 5-66. bizhub 360 3-49...
  • Page 168 Basic Copy Operations Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 3-50 bizhub 360...

  • Page 169: To Make Double-Sided Copies Using Original Glass

    Open the ADF. Position the original on original glass, then close the ADF. – Place the original FACE DOWN from the first page (page 1). For de- tails, see “To position the original on original glass” on page 3-9. bizhub 360 3-51...
  • Page 170 Specify the original set direction according to the orientation of posi- tioned original. – Touch [Original Direction] to display the Original Direction Screen. – Select one of the original direction key according to the orientation of positioned original, then touch [OK]. 3-52 bizhub 360...
  • Page 171 When completed, the message “Scanning stopped./ Press [Start] to continue.” will be displayed in the message area. Replace the original on the original glass with the second page (page 2), then press [Start]. – Repeat this step for all original pages to be scanned. bizhub 360 3-53...
  • Page 172 [OK] to return to the Basic Screen. Note Using the original glass to scan the double-sided original, it does not matter which of the two duplex modes (1%2 or 2%2) is specified. 3-54 bizhub 360...

  • Page 173: To Make Single-Sided Copies From Double-Sided Original

    8-1/2 × 11 or smaller landscape-type original with right/left margin creat- 8-1/2 × 14 or larger portrait-type original with right/left margin created 8-1/2 × 14 or larger landscape-type original with top margin created. Position the original in the ADF. bizhub 360 3-55...
  • Page 174 Specify the original set direction according to the orientation of posi- tioned original. – Touch [Original Direction] to display the Original Direction Screen. – Select one of the original direction key according to the orientation of positioned original, then touch [OK]. 3-56 bizhub 360...
  • Page 175 “Specifying Position of Binding Margin (Margin)” on page 4-17. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 3-57...

  • Page 176: Separate Scan Setting

    0 Separate Scan mode is necessarily used and operates automatically in the following functions: Making double-sided copies using original glass Image Insert Book Copy Position the original. – When using the original glass, place the first page face down on the original glass. 3-58 bizhub 360...
  • Page 177 – When using the ADF, load the original arranged in page order with page one on the top. Touch [Separate Scan] on the Basic Screen. Select additional copy conditions, as desired. Press [Start] on the control panel. bizhub 360 3-59...
  • Page 178 When completed, the message “Scanning stopped./ Press [Start] to continue.” will be displayed in the message area. Replace the original, then press [Start]. – Repeat steps 4 and 5 for all original pages to be scanned. When all the original pages are scanned, touch [Finish] 3-60 bizhub 360...
  • Page 179 To delete the scanned image data, press [Stop]. For details, see “To Stop/Resume/Delete a Job” on page 3-67. Note The memory indicator in the upper-right corner of the Basic Screen al- lows you to check the remainder of memory during the scanning job. bizhub 360 3-61...

  • Page 180: Setting Job During Warmup

    The LED of the [Start] key will lights in green. Position the original. Set the desired copy conditions, and enter the print quantity. Press [Start] on the control panel. The original will be scanned into memory, and a print job will be on standby. 3-62 bizhub 360...
  • Page 181 The standby jobs can be checked for the settings, rearranged with prior- ity in output order, and also be cancelled. For details, see Section 8: Job Management. To suspend the job in progress, press [Stop]. For details, see “To Stop/Resume/Delete a Job” on page 3-67. bizhub 360 3-63...

  • Page 182: Next Job Reservation

    – When the original is all scanned and the machine starts printing, the Basic Screen will be restored with the message “Ready to accept another job” displayed in the message area. 3-64 bizhub 360...
  • Page 183 Select copy conditions and enter the print quantity for the next job. Press [Start] on the control panel. When the current printing job is completed, the reserved job will auto- matically start printing. To reserve more than one job, repeat the steps from 1 to 3. bizhub 360 3-65...
  • Page 184 The standby jobs can be checked for the settings, rearranged with prior- ity in output order, and also be cancelled. For details, see Section 8: Job Management. To suspend the job in progress, press Stop. For details, see “To Stop/Resume/Delete a Job” on page 3-67. 3-66 bizhub 360...

  • Page 185: To Stop/Resume/Delete A Job

    Touch [Job List] to delete the scanned data. For details, see Section 8: Job Management. Press [Stop] on the control panel during scanning/printing. The scanning/printing will be suspended and the Job Stop Screen will be displayed. bizhub 360 3-67...

  • Page 186: To Delete A Suspended Job

    0 The scanned data of reserved job can be deleted by touching [Job List], to cancel printing. For details, see Section 8: Job Management. Press [Stop] on the control panel during scanning/printing. The scanning/printing will be suspended and the Job Stop Screen will be displayed. 3-68 bizhub 360...
  • Page 187 Basic Copy Operations Touch and highlight the job to be deleted, then touch [Delete]. Selected job will be deleted. bizhub 360 3-69...

  • Page 188: Copy Conditions Incompatible With Basic Settings

    1.0 Zoom Preset Zoom , , , Zoom Ratio , , , , , , , Independent Zoom single-sided originals double-sided original Simplex /Duplex single-sided copies + + + + + + double-sided copies Separate Scan 3-70 bizhub 360...
  • Page 189 *4 *4 *4 Auto Zoom *4 *4 *4 x 1.0 Zoom *4 *4 *4 Enlarge and Reduce *4 *4 *4 Zoom Ratio Independent Zoom *4 *4 *4 single-sided originals double-sided original Simplex /Duplex single-sided copies double-sided copies Separate Scan bizhub 360 3-71...
  • Page 190 Envelope , , , , , , *4 Auto Zoom x 1.0 Zoom Preset Zoom Zoom Ratio Independent Zoom single-sided originals double-sided , , , Simplex/ original Duplex single-sided copies , , , double-sided copies Separate Scan 3-72 bizhub 360...
  • Page 191 *3: Condition last selected has priority only when Copy Insertion is selected. *4: Condition last selected has priority when recommended zoom ratio is used in Combine Originals or Booklet. *6: Varies according to the finishing option to be used. *7: Offset mode will be ignored. bizhub 360 3-73...

  • Page 193: Combine Originals/Original Image Type

    Combine Originals/ Original Image Type...

  • Page 194: Lay Out Multiple Pages Onto One Sheet (Combine

    The following functions are provided to Combine Pages. The direction of the page arrangement will vary according to the specified original binding mar- gin. Setting Description item 2 in 1 Select this setting to print two original images onto one sheet. Left binding Right binding bizhub 360...
  • Page 195 4 in 1 Select this setting to print four original images onto one sheet. The page arrangement (Numbering Direction) can be specified. Horizontal order, left binding Horizontal order, right binding Vertical order, left binding Vertical order, right binding bizhub 360...
  • Page 196 - 4 in 1: ×0.500 - 8 in 1: ×0.323 Detail The machine can be set to disable the automatic selection of recom- mended zoom ratio in order to accept the ratio entered manually. For details, see page 14-31. bizhub 360...

  • Page 197: To Copy Using Combine Pages

    To specify original di- rection on page 4-12. – When positioning the original on original glass, use the Sepa- rate Scan mode to scan the original im- age into memory. For details, see Separate Scan Setting on page 3-58. bizhub 360...
  • Page 198 When selecting [4 in 1] or [8 in 1], touch [Horizontal] or [Vertical] to specify the direction of page arrangement. – If changing the direction of page arrangement to start from the right side, touch [Margin] to select [Right], then touch [OK]. bizhub 360...
  • Page 199 If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. Detail If change the direction of paper arrangement to start from the right side, specify the margin of copy image. For details, see page 5-66 bizhub 360...

  • Page 200: Specifying Original Settings (Original)

    0 Do not load more than 80 sheets of the original, otherwise the original may be misfed or damaged, or machine trouble may be caused. If the number of original sheets exceeds 80, divide them into blocks to scan. For details, see “Separate Scan Setting” on page 3-58. bizhub 360...
  • Page 201 Position the original FACEUP (with the first page UP) in the ADF. – Align the left and rear sides of the original to the ADF, then ad- just the paper guides. bizhub 360...

  • Page 202: Copying Z-Folded Original (Z-Folded Original)

    4.2.2 Copying Z-Folded Original (Z-Folded Original) If folded original are loaded in to the ADF to be copied, the original size is correctly detected. To copy using Z-Folded Original 0 Load the original in to the ADF. 4-10 bizhub 360...
  • Page 203 0 The length of the first page of the original is detected, and all pages of the original are scanned at that size. Position the original to be copied. Touch [Combine Originals]. The Combine Original Screen will be displayed. Touch [Z-Folded Original]. bizhub 360 4-11...

  • Page 204: Specifying Orientation Of Original (Original Direction)

    Using original Icon Description glass Select for the original positioned with the top toward the rear of the machine. Initially selected as factory default. Select for the original positioned with the top toward the front of the machine. 4-12 bizhub 360...
  • Page 205 Note The difference in original type (portrait or landscape) does not matter to the Original Direction setting. Specify the orientation of original simply ac- cording to where the top of the original is positioned. bizhub 360 4-13...

  • Page 206: To Specify Original Direction

    The Basic Screen with the original loaded in the ADF – The Basic Screen with the original placed on the original glass The Combine Originals Screen will be displayed. Touch [Original Direction]. The Original Direction Screen will be displayed. 4-14 bizhub 360...
  • Page 207 The Original Direction setting will not be cleared after a job completion until the reset function is activated. The machine can be set to reset the Original Direction setting to the fac- tory default each time a single job is completed. For details, see page 15-74. bizhub 360 4-15...
  • Page 208 Press [Reset] on the control panel to restore the factory default setting. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 4-16 bizhub 360...

  • Page 209: Specifying Position Of Binding Margin (Margin)

    8-1/2 x 11 or smaller 8-1/2 x 14 or larger Select for the double-sided original bound on the left side. Select for the double-sided original bound on the right side. Select for the double-sided original bound on the top side. bizhub 360 4-17...

  • Page 210: To Specify Margin

    For details, see page 15-74. Load the original in the ADF. Touch [Combine Originals] tab on the Basic Screen. The Combine Originals Screen will be displayed. Touch [Margin]. The Page Margin Screen will be displayed. 4-18 bizhub 360...
  • Page 211 Press [Reset] on the control panel to restore the factory default setting. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 4-19...

  • Page 212: Making Copy Quality Closer To Original (Original Image Type)

    Select to reproduce a half-tone photo image. The copy will closely rep- resent the half-tones of the original image. Original Photo mode Select for copying the original composed of text only, in order to darken lightly printed images (e.g. pencil) to improve the legibility. Original Dot Matrix mode 4-20 bizhub 360...

  • Page 213: To Specify Original Image Type

    Press [Reset] on the control panel to restore the factory default setting. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 4-21...

  • Page 214: Copy Conditions Incompatible With Combine Originals/ Original Image Type Settings

    + + + + + 4in1 Pages + + + + + 8in1 , , , + + + + + Mixed Original Original Direction Original Settings Margin , , , Text Text/Photo Photo , , , Dot Matrix 4-22 bizhub 360...
  • Page 215 +: Condition previously selected has priority and warning message will be displayed. *4: Condition last selected has priority when recommended zoom ratio is used in Combine Originals or Booklet. *8: Incompatible when Booklet is automatically selected with Half Fold or Fold & Staple in combination. bizhub 360 4-23...

  • Page 217: Application Functions

    Application Functions...

  • Page 218: Copying Onto Ohp Transparencies (Ohp Interleave)

    The interleaf can be kept blank, or copied from the same original as transparency. Function overview The following functions are provided in OHP Interleave. Function Description Copy onto interleaf Insert an interleaf with the same image copied as transparency. Use blank interleaf Insert a blank interleaf between transparencies. bizhub 360...

  • Page 219: To Copy Using Ohp Interleave

    Fold & Staple, nor Half Fold mode can be used. Position the original. Load OHP transparencies in the bypass tray. – Load one sheet at a time. The Paper Screen will be displayed on the touch panel. bizhub 360...
  • Page 220 Touch [OHP] to highlight it, then touch [OK]. The Paper Screen will be restored. Load copy paper in any tray other than bypass tray to match the size of OHP transparencies. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360...
  • Page 221 Select [Copy] or [Blank]. – To copy the original image also onto interleaves, touch [Copy] un- der Copy or Blank to highlight it. – To leave the interleaves blank, touch [Blank] under Copy or Blank to highlight it. bizhub 360...
  • Page 222 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360...

  • Page 223: Adding Covers (Cover Mode)

    Back (Blank) A blank sheet for back cover will be inserted as the last sheet of copied set. The same result will be obtained when making double-sided copies. bizhub 360...

  • Page 224: To Copy Using Cover Mode

    When using thick paper for covers, load it into the bypass tray, then specify the paper type as Thick in paper setting for bypass tray. For details, see “To specify paper type” on page 3-27. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360...
  • Page 225 If no front cover is needed, deselect both keys. – To attach the back cover, touch either [Back (Copy)] or [Back (Blank)] to highlight it. If no back cover is needed, deselect both keys. – The front cover setting is compatible with back cover setting. bizhub 360...
  • Page 226 Touch [OK] to complete the setting on each screen, then return to the Application Screen. – Touch [Cancel] on the Cover Mode Screen to cancel the setting change. Select additional copy conditions, as desired. Press [Start] on the control panel. 5-10 bizhub 360...
  • Page 227 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 5-11...

  • Page 228: Adding Insertions (Insert Sheet)

    4th sheet of copied set. The 5th page of double-sided original is simplex-copied onto the inser- tion, which will be the 5th sheet of copied set. 5-12 bizhub 360...
  • Page 229 With page 6 specified, a blank insertion will be added as the 4th sheet of copied set, after the 5th and 6th pages of double-sided original are duplex-copied. A blank insertion will be added as the 6th sheet of copied set, after the 5th page of double-sided original is simplex-copied. bizhub 360 5-13...

  • Page 230: To Copy Using Insert Sheet

    Select the Simplex/Duplex mode. – For details on specifying Simplex/Duplex mode, see “Simplex/Du- plex Setting” on page 3-46. Load paper for insertions into the desired tray. – The bypass tray is also available as insertion tray source. 5-14 bizhub 360...
  • Page 231 Application Functions Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Sheet/Cover/Chapter Insert], then touch [Insert Sheet]. The Insert Sheet Screen will be displayed. bizhub 360 5-15...
  • Page 232 % The entered page number will be ignored. Do you want to delete the page number once entered? % Touch and highlight the page number key to be cleared, then press [C] (Clear) on the control panel. Specify the tray loaded with insertions. 5-16 bizhub 360...
  • Page 233 Application Functions – Touch [Insert Paper], select the insertion tray source to highlight it, then touch [OK]. bizhub 360 5-17...
  • Page 234 Touch [OK] to return to the Application Screen. – Touch [Cancel] on the Insert Sheet Screen or Insert Sheet Check Screen to cancel the setting change. Select additional copy conditions, as desired. Press [Start] on the control panel. 5-18 bizhub 360...
  • Page 235 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 5-19...

  • Page 236: Inserting Different Original Images Into Printed Sets (Insert Image)

    1%2 mode. The first scanned image will be inserted after page 2 of the finished set, and the second scanned image will be inserted after page 5. 5-20 bizhub 360...

  • Page 237: To Copy Using Insert Image

    Enter the desired print quantity from the control panel keypad. Select the Simplex/Duplex mode. – For details on specifying Simplex/Duplex mode, see “Simplex/Du- plex Setting” on page 3-46. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360 5-21...
  • Page 238 The Insert Image Check Screen will be displayed. What if the specified locations are fewer than the scanned insertion images? % The insertion images exceeding specified locations will be added at the end of the finished set. 5-22 bizhub 360...
  • Page 239 The machine starts scanning the original to have image insertions. Place the original of image insertion on the original glass. – When scanning the ADF original is completed, open the ADF. Posi- tion the insertion original facedown on the original glass, then close the ADF. bizhub 360 5-23...
  • Page 240 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 5-24 bizhub 360...

  • Page 241: Locating Title Pages On Front Side (Chapters)

    (2/3 and 5/6) will be printed on paper from another tray source. Insert Since one double-sided original sheet is counted as two pages, the Chapter paper: None copy result will be exactly the same as above in 1%2 mode with None selected for Chapter paper. bizhub 360 5-25...

  • Page 242: To Copy Using Chapters

    Enter the desired print quantity from the control panel keypad. Select [1%1] or [2%1] mode. – For details on specifying “Simplex/Duplex Setting” on page 3-46. 5-26 bizhub 360...
  • Page 243 Application Functions Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Sheet/Cover/Chapter Insert], then touch [Chapters]. The Chapters Screen will be displayed. bizhub 360 5-27...
  • Page 244 % Touch and highlight the page number key to be cleared, then press [C] (Clear) on the control panel. Change the tray selection for title pages, if desired. – Touch [Copy Insert], if not highlighted, to display the [Chapter Pa- per] key. 5-28 bizhub 360...
  • Page 245 Check the locations on the Chapters Check Screen, and make setting change, if desired. – To change the tray selection for title pages, return to the previous step. – To change the title page number, touch [Edit] and return to step 6. bizhub 360 5-29...
  • Page 246 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 5-30 bizhub 360...

  • Page 247: Scanning Documents With Different Settings And Printing Copies All Together ("Program Job" Function)

    Position the original FACE UP in the ADF or FACE DOWN one the orig- inal glass. – If the number of ADF originals exceeds100, them into blocks not exceeding 100 sheets and load them from the block with the first page. bizhub 360 5-31...
  • Page 248 The Application Screen will be displayed. Touch [Sheet/Cover/Chapter Insert], then touch [Program Job]. Select the desired copy settings, and then press [Start] on the control panel. – To print a single copy to be checked, touch [Proof Copy]. Scanning begins. 5-32 bizhub 360...
  • Page 249 Select the desired copy settings, and then press [Start] on the control panel. – To print a single copy to be checked, touch [Proof Copy]. – Repeat steps 6 and 7 until all original batches have been scanned. The amount of memory available can be checked beside “Memory” bizhub 360 5-33...
  • Page 250 After all document pages have been scanned, touch [Finish]. A message appears, requesting confirmation that scanning is finished. Select [Yes], and then touch [OK]. – To change the copy settings, select [No], and then touch [Change Setting]. Specify any other desired copy settings. 5-34 bizhub 360...
  • Page 251 Using the keypad, type in the desired number of copies. Touch [Execute] or press [Start] on the control panel. – If [Cancel] is touched, a message appears, requesting confirmation to delete the data. To stop printing, select [Yes], and then touch [OK]. bizhub 360 5-35...

  • Page 252: Dividing Spread Image Into Right And Left Pages (Book Copy)

    Front Cover Printed sets will be output from the front cover page, then divided doc- ument pages according to pagination. The original should be scanned from the front cover, then page spread originals in page order. 5-36 bizhub 360...

  • Page 253: To Copy Using Book Copy

    0 Using Book Copy along with Centering, the original can be placed any- where on the original glass. 0 Use Erase/Center Erase to copy eliminating black copy marks along bor- ders. 0 Auto Zoom will not function. The magnification can be changed as de- sired. bizhub 360 5-37...
  • Page 254 – When using Centering in combination, the original can be located at any place provided it is not skewed. Enter the desired print quantity from the control panel keypad. Load the desired copy paper into any tray. 5-38 bizhub 360...
  • Page 255 Touch the desired tray key to highlight it. Without this tray selection, the machine will automatically use copy paper loaded in tray 1 to print. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Book Copy/Repeat]. The Book Copy/Repeat Screen will be displayed. bizhub 360 5-39...
  • Page 256 [Left Bind] or [Right Bind] in the Position area. – If necessary, touch [Erase] or [Center Erase] in the Book Erase area to display the Erase Screen or Center Erase Screen to use each function. For details of setting procedure, see “Erasing Black Marks along 5-40 bizhub 360...
  • Page 257 – When selecting Front and Back Cover mode, scan the original in the order of front cover, back cover, and then spread originals. – When selecting Front Cover mode, scan the front cover first, then spread originals. bizhub 360 5-41...
  • Page 258 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. 5-42 bizhub 360...

  • Page 259: Repeating Original Image On One Sheet (Image Repeat)

    Use the ADF or original glass to scan the original. Specify the number of repeats from 2, 4, and 8 times, irrespective of the original image size. The original image size can be both detected automatically (Auto Detect) or specified manually (Set Range). bizhub 360 5-43...

  • Page 260: Function Overview

    Application Functions Function overview Function Mode Description Auto Repeat Auto Detect + With Margin Auto Detect + Without Margin Set Range + With Margin Set Range + Without Margin 2/4/8 Repeat 2 Repeat 4 Repeat 8 Repeat 5-44 bizhub 360...

  • Page 261: Setting Repeat Times Automatically

    0 Auto Zoom will not function. Specify the desired magnification ratio. Position the original on the original glass. – Keep the ADF open. Enter the desired print quantity from the control panel keypad. Load the desired copy paper into any tray. bizhub 360 5-45...
  • Page 262 Touch the desired tray key to highlight it. Without this tray selection, the machine will automatically use copy paper loaded in tray 1 to print. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-46 bizhub 360...
  • Page 263 Application Functions Touch [Book Copy/Repeat], then touch [Image Repeat]. The Image Repeat Screen will be displayed. Specify the desired Layout mode. – Touch [With Margin] or [Without Margin] to highlight it. bizhub 360 5-47...
  • Page 264 In or- der to specify a fraction, touch the bidirectional arrow key to move the cursor, then use [+] and [–] to enter the desired value in 1/16 in. increments. – When selecting [Set Range], Close the ADF. 5-48 bizhub 360...
  • Page 265 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-49...

  • Page 266: Specifying Repeat Times (2/4/8 Repeat)

    Touch [Paper] on the Basic Screen to display the Paper Screen. – Touch the desired tray key to highlight it. Without this tray selection, the machine will automatically use copy paper loaded in tray 1 to print. 5-50 bizhub 360...
  • Page 267 Application Functions Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Book Copy/Repeat], then touch [Image Repeat]. The Image Repeat Screen will be displayed. bizhub 360 5-51...
  • Page 268 [+] and [–] to enter the desired value in 1/16 in. increments. – Touch [OK] to return to the Image Repeat Screen. 5-52 bizhub 360...
  • Page 269 Proceed to step 11. – Select [8 Repeat] to repeat the original image eight times on a print- ed page. Proceed to step 11. Does the Rotation work with this mode selected? % Yes, it will function automatically. bizhub 360 5-53...
  • Page 270 Touch [Cancel] on the Image Repeat Screen, 2/4/8 Repeat Screen, or Repeat Interval Setting Screen to cancel the setting change. Select additional copy conditions, as desired. Press [Start] on the control panel. The machine will start printing when ready for output. 5-54 bizhub 360...
  • Page 271 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-55...

  • Page 272: Dividing Spread Image Into Right And Left Pages Using Adf (Booklet

    0 Auto Zoom will not function. The magnification can be changed as de- sired. Position the original in the ADF. Enter the desired print quantity from the control panel keypad. Load copy paper of size A4v, B5v, and 8-1/2”×11”v in any tray. 5-56 bizhub 360...
  • Page 273 Touch [Paper] on the Basic Screen to display the Paper Screen. – Touch the desired tray key to select the tray loaded with A4v, B5v, and 8-1/2”×11”v paper. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360 5-57...
  • Page 274 On the contrary, if the spread original reads from the right page to the left page, touch [Right Bind]. Touch [OK] to return to the Application Screen. – Touch [Cancel] on the Booklet Pagination Screen to cancel the set- ting change. Select additional copy conditions, as desired. 5-58 bizhub 360...
  • Page 275 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-59...

  • Page 276: Making Multiple Page Signature Booklet (Booklet)

    ×0.647 and an appropriate paper size with Auto Paper Select activated. The machine can be set to change the recommended magnification ratio manually. For details, see page 14-31. 0 The binding margin will be automatically specified. 5-60 bizhub 360...
  • Page 277 Load the original in the ADF. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Booklet] on the Application Screen. The Booklet Screen will be displayed. bizhub 360 5-61...
  • Page 278 Use the Edit Margin function to adjust the image position widthwise and lengthwise as desired, while Page Interval simply makes a blank space between the images. For details of the Edit Margin function, see page 5-70. – When the adjustment is completed, touch [OK]. 5-62 bizhub 360...
  • Page 279 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-63...

  • Page 280: Reversing Color And Gradation Of Image (Neg-Pos. Reverse)

    Function overview To copy using Neg-/Pos. Reverse Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-64 bizhub 360...
  • Page 281 To resume the initial setting for all settings including application function, press [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 5-65...

  • Page 282: Creating Margin Of Copy Image

    Function overview Function Description Creating binding mar- (Page Margin) Selecting binding po- sition (Page Margin) Adjusting image posi- tion on front/back sides (Edit Margin) 5-66 bizhub 360...

  • Page 283: 5.12.1 Creating Binding Margin/ Selecting Binding Position

    0 Staple and punch position settings will take priority if they conflict with the specified binding position. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360 5-67...
  • Page 284 When [None] is highlighted, the margin is automatically set to 0 in. Use [None] for correcting the image orientation of double-sided copy. What should be done if wrong value is entered? % Press [C] (Clear) on the control panel, then reenter the correct value. 5-68 bizhub 360...
  • Page 285 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-69...

  • Page 286: Adjusting Image Position On Front/Back Sides (Edit Margin)

    0 The front- and back-side images of double-sided copy can be shifted separately in order to correct the image dislocation. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-70 bizhub 360...
  • Page 287 Application Functions Touch [Page Margin], then touch [Edit Margin]. The Edit Margin Screen will be displayed. bizhub 360 5-71...
  • Page 288 % Press [C] (Clear) on the control panel, then reenter the correct value. Is it available to change the shift direction even if the shift amount is already specified? % Yes. The shift direction can be changed at any time. 5-72 bizhub 360...
  • Page 289 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-73...

  • Page 290: Erasing Specified Area Of Copy (Erase)

    Erases black copy marks along borders of the original image. Center Erase Erases black copy marks along the center line of the original. Non-Image Area Detects the original size and erases outside area of the original. Erase 5-74 bizhub 360...

  • Page 291: Erasing Black Marks Along Borders (Erase)

    When using Non-Image Area Erase in combination, scan the original from the original glass. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360 5-75...
  • Page 292 Use [+] and [–] to enter a fraction in 1/16 in. increments. Touch the bidirectional arrow key to move the cursor, then use [+], [–], or con- trol panel keypad to enter whole number part of the desired value. Or, touch [None] to void the function on that side. 5-76 bizhub 360...
  • Page 293 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-77...

  • Page 294: Erasing Black Marks Along Center Fold (Center Erase)

    When using Non-Image Area Erase in combination, scan the original from the original glass. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-78 bizhub 360...
  • Page 295 % Press [C] (Clear) on the control panel, then enter the correct value. What if the value just entered is out of available range? % The Input Error message will be displayed. Press [C] (Clear) on the control panel, then reenter the correct value. bizhub 360 5-79...

  • Page 296: Erasing Outside Area Of Original (Non-Image Area Erase)

    0 Original size should be larger than 1.18 × 1.18 in. 0 Available to be used together with Erase and Center Erase. Position the original on the original glass. Enter the desired print quantity from the control panel keypad. 5-80 bizhub 360...
  • Page 297 The Erase Screen will be displayed. Touch [Non-Image Area Erase] on the Erase Screen to highlight it. Touch [OK] to return to the Application Screen. – To release the selected application function, touch [Non-Image Area Erase]. Select additional copy conditions, as desired. bizhub 360 5-81...
  • Page 298 In this case, check this function using the original with white back- ground. This function may also perform incorrectly if the lighting in the work place is directly over the original glass. In this case, consult your service repre- sentative about an appropriate place for installation. 5-82 bizhub 360...

  • Page 299: Adjusting Position Of Copy Image (Image Adjustment)

    8-1/2 x 11 8-1/2 x 11 5-1/2 x 8-1/2 5-1/2 x 8-1/2 8-1/2 x 11 8-1/2 x 14 8-1/2 x 11 8-1/2 x 11 5-1/2 x 8-1/2 8-1/2 x 11 5-1/2 x 8-1/2 5-1/2 x 8-1/2 5-1/2 x 8-1/2 bizhub 360 5-83...

  • Page 300: Copying Image In The Center Of Copy Paper (Centering)

    Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Image Adjustment] on the Application Screen. The Image Adjustment Screen will be displayed. 5-84 bizhub 360...
  • Page 301 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-85...

  • Page 302: Disabling Rotation Function (No Rotate)

    0 When [Reset] on the control panel is pressed or Auto Reset function op- erates on the machine, the Rotation function will be turned on automati- cally even if disabled by this procedure. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-86 bizhub 360...
  • Page 303 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-87...

  • Page 304: Printing Additional Information (Stamp/Overlay)

    - Image Overlay Copies can be printed with the first image scanned overlapping images later scanned. - Store Overlay A previously scanned image can be stored on the HDD and recalled when needed to be printed overlapping a document. 5-88 bizhub 360...

  • Page 305: Function Overview

    Application Functions Function overview The following five modes are provided for the Stamp function. These are compatible with each other. Mode Description Date/Time ’06/1/23 1:23PM Page # Set Numbering bizhub 360 5-89...
  • Page 306 Application Functions Mode Description Built-in Stamp Watermark Image Overlay ABCD ABCD ABCD ABCD Store Overlay ABCD ABCD ABCD ABCD 5-90 bizhub 360...

  • Page 307: Printing Date/Time (Date/Time)

    0 Select to print the date/time either on the cover or on all pages. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. bizhub 360 5-91...
  • Page 308 Touch either of the two keys under Pages to highlight it. – To change or make fine adjustment on the print position currently specified as indicated on the Print Position key, proceed to the next step. To complete this setting, proceed to step 8. 5-92 bizhub 360...
  • Page 309 Application Functions Touch [Print Position] on the Date/Time Screen to specify the desired print position. – Touch one of the nine Print Position keys to highlight it. – If fine adjustment is not required, proceed to step 8. bizhub 360 5-93...
  • Page 310 % Press [C] (Clear) on the control panel, then enter the correct value. What if the value just entered is out of available range? % The Input Error message will be displayed. Press [C] (Clear) on the control panel, then reenter the correct value. 5-94 bizhub 360...

  • Page 311: Printing Page Number (Page #)

    0 The desired print position can be selected from nine areas. If required, make fine adjustment of the selected position both in lengthwise and widthwise directions by entering a value from 1/16 to 1-15/16 in. in 1/16 in. increments. Position the original. bizhub 360 5-95...
  • Page 312 Application Functions Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Stamp/Overlay], then touch [Page #]. The Page # Screen will be displayed. 5-96 bizhub 360...
  • Page 313 % Press [C] (Clear) on the control panel, then enter the correct value. What if the value just entered is out of available range? % The Input Error message will be displayed. Press [C] (Clear) on the control panel, then reenter the correct value. bizhub 360 5-97...
  • Page 314 Touch [OK] to complete the setting. Touch [Print Position] to display the Print Position Screen. – Touch one of the nine Print Position keys to highlight it. – If fine adjustment is not required, proceed to step 9. 5-98 bizhub 360...
  • Page 315 Touch [Cancel] on the Page # Screen, Insert Sheet Setting Screen, Print Position Screen, or Fine-Tune Screen to cancel the setting change. Select additional copy conditions, as desired. Press [Start] on the control panel. The machine will start scanning the original, then printing when ready for output. bizhub 360 5-99...

  • Page 316: Printing Distribution Number (Set Numbering)

    0 Select whether to print the distribution number on the cover only or on all pages. 0 Select the character size from 20pt or 36pt. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-100 bizhub 360...
  • Page 317 – Touch [Character Size] to select 20 point or 36 point. Do you want to change the currently entered value using control panel keypad? % Press [C] (Clear) on the control panel, then enter the correct value. bizhub 360 5-101...

  • Page 318: Printing Stamp Onto Copies (Built-In Stamp)

    0 Select to print the stamp either on the cover or on all pages. 0 Select the character size from large size or small size. Position the original. Enter the desired print quantity from the control panel keypad. 5-102 bizhub 360...
  • Page 319 Application Functions Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Stamp/Overlay], then touch [Built-in Stamp]. The Built-in Stamp Screen will be displayed. bizhub 360 5-103...
  • Page 320 To complete this setting, proceed to step 8. Touch [Print Position] to display the Print Position Screen. – Touch one of the nine Print Position keys to highlight it. – If fine adjustment is not required, proceed to step 8. 5-104 bizhub 360...
  • Page 321 Touch [Cancel] on the Built-in Stamp Screen, Print Position Screen, or Fine-Tune Screen to cancel the setting change. Select additional copy conditions, as desired. Press [Start] on the control panel. The machine will start scanning the original, then printing when ready for output. bizhub 360 5-105...

  • Page 322: Printing Watermark Onto Copies (Watermark)

    0 Select one from the eight watermark types provided on the screen. Position the original. Enter the desired print quantity from the control panel keypad. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-106 bizhub 360...
  • Page 323 Select the desired watermark type. – Touch one of the eight keys to highlight it. Touch [OK] to return to the Application Screen. – Touch [Cancel] on the Watermark Screen to cancel the setting change. Select additional copy conditions, as desired. bizhub 360 5-107...

  • Page 324: Overlay An Image Onto Each Page Copied In The Job (Image Overlay)

    0 Separate Scan mode is automatically selected. Position the overlaying original. Position the original FACE up in the document feeder or FACE DOWN on the original glass. Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. 5-108 bizhub 360...
  • Page 325 Press [Start] on the control panel. The original image will be scanned into memory, and the following screen will be displayed. Position the original to be overlaid. Press [Start] to scan. – Repeat steps 5 and 6 for all originals. bizhub 360 5-109...

  • Page 326: Storing Image On Hdd / Overlaying Stored Image (Store Overlay)

    To make a copy using the image previously stored, start with step 9. To copy using Store Overlay Position the overlaying original. Position the original FACE up in the document feeder or FACE DOWN on the original glass. 5-110 bizhub 360...
  • Page 327 Application Functions Touch [Application] tab on the Basic Screen. The Application Screen will be displayed. Touch [Stamp/Overlay], then touch [Store Overlay]. The Overlaying Image Selection Screen will be displayed. bizhub 360 5-111...
  • Page 328 Touch [Change] to display the Image Name Entry Screen. Use the touch panel keypad to enter the desired name up to 8 characters. The date when you made this entry will be stored autommatically. – Touch [OK]. 5-112 bizhub 360...
  • Page 329 The scanned image will be registered and the Basic Screen will be re- stored. Position the original to be overlaid. Repeat steps 2 and 3 to display the Overlaying Image Selection Screen. Recall the desired overlaying image. bizhub 360 5-113...
  • Page 330 – Select additional copy conditions, as desired. Press [Start]. The original to be overlaid will be scanned into memory. Touch [Complete Scan] on the Basic Screen. Press [Start]. The machine will start printing when ready for output. 5-114 bizhub 360...
  • Page 331 [Reset] on the control panel. Note If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Application Screen or Basic Screen. bizhub 360 5-115...

  • Page 332: Copy Conditions Incompatible With Application Functions

    Erase Erase Non-Image Area Erase Centering No Rotation Image Adjustment Original Size Setting Custom Size Originals + + + + + + + *4 *4 *4 *4 Booklet Set Numbering Page # Stamp Date/Time Built-in Stamp Watermark 5-116 bizhub 360...
  • Page 333 + + + + + + + + Centering + + + No Rotation Image Adjustment Original Size Setting Custom Size + + + , Originals + + + + Booklet Set Numbering Page # Stamp Date/Time Built-in Stamp Watermark bizhub 360 5-117...
  • Page 334 + + + + + + + + + + Booklet + + + Set Numbering + + + + + Page # Stamp + + + + + Date/Time + + + + + Built-in Stamp + + + Watermark 5-118 bizhub 360...
  • Page 335 +: Condition previously selected has priority and warning message will be displayed. *3: Condition last selected has priority only when Copy Insertion is selected. *4: Condition last selected has priority when recommended zoom ratio is used in Combine Originals or Booklet. bizhub 360 5-119...

  • Page 337: Finishing/Folding

    Finishing/Folding...

  • Page 338: Output For Machine Without Finisher

    8-1/2 × 11- or 5-1/2 × 8-1/2 size paper. bizhub 360...

  • Page 339: Function Overview

    Finishing/Folding Function overview Mode Sample Sort Group Sort and Offset Group and Offset bizhub 360...

  • Page 340: To Specify Output Mode

    When using an alternating crisscross pattern, load 8-1/2 × 11- or 5- 1/2 × 8-1/2-size paper with crosswise orientation v in one paper tray and with the lengthwise orientation w in other tray. Touch [Finishing] on the Basic Screen. The Finishing Screen will be displayed. bizhub 360...
  • Page 341 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360...

  • Page 342: Output For Machine With Finisher

    Finisher FS-510 is initially equipped with two exit trays, and one optional output tray OT-601 can be installed. Contact your service representative, if desired. (Optional output tray is installed in Finisher illustrated above) Finisher FS-510 is available to output in each tray using every output mode. bizhub 360...

  • Page 343: Function Overview

    Finishing/Folding Function overview Mode Sample Sort Group Sort + Offset 1.18 in. Group + Offset 1.18 in. bizhub 360...

  • Page 344: To Specify Finisher Output Mode

    Select Sort or Group, and set Offset to use offset output. – To set Sort mode, touch [Sort] to highlight it. – To set Group mode, touch [Group] to highlight it. – To set Sort in offset output, touch [Sort] and [Offset] to highlight them. bizhub 360...
  • Page 345 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360...

  • Page 346: Stapling Output Copies (Staple)

    (Already installed in the above illustration.) Function overview The Original Direction setting for the samples below is supposed to be the one which the top of the original is aligned to the rear side of the machine. Sample 6-10 bizhub 360...
  • Page 347 Finishing/Folding Sample bizhub 360 6-11...

  • Page 348: To Copy Using Staple Mode

    For setting Original Direction, see “Specifying Orientation of Origi- nal (Original Direction)” on page 4-12. For setting Margin, see “Paper Tray/ Output Tray Capacity” on page 9-4. – When completed, touch [Basic] tab to return to the Basic Screen. 6-12 bizhub 360...
  • Page 349 To staple along the edge, touch [2 Position] to highlight it. Select staple position. – Touch [Position] to display the Staple Position popup menu. – Touch the desired key to highlight it. Touch [OK] twice. The Basic Screen will be restored. bizhub 360 6-13...
  • Page 350 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 6-14 bizhub 360...

  • Page 351: Punching File Holes In Copies (Punch)

    (Already installed in the above illustration.) Function overview The Original Direction setting for the samples below is supposed to be the one which the top of the original is aligned to the rear side of the machine. Sample bizhub 360 6-15...

  • Page 352: To Copy Using Punch Mode

    Using the keypad, enter the desired number of copies. Touch [Combine Originals] tab on the Basic Screen, then make Original Direction and Margin settings. – For setting Original Direction, see “Specifying Orientation of Origi- nal (Original Direction)” on page 4-12. 6-16 bizhub 360...
  • Page 353 The Finishing Screen will be displayed. Touch [][2-Hole] or [3-Hole] to highlight it. – Group and Offset are also available in combination. Touch the de- sired key to highlight it. – To cancel the setting, touch the button again to deselect it. bizhub 360 6-17...
  • Page 354 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. 6-18 bizhub 360...

  • Page 355: Folding Copies At The Center/Binding Copies At The Center: Half Fold/ Fold & Staple

    (saddle stitched), then output to the Saddle stitcher tray. Note Finisher FS-510 is initially equipped with two exit trays, and one optional exit tray (OT-601) can be installed. Contact your service representative, if desired. (Already installed in the above illustration.) Function overview Description bizhub 360 6-19...

  • Page 356: To Copy Using Half Fold Or Fold & Staple

    & Staple mode. Using the keypad, enter the desired number of copies. – Be sure that the output sheets may not exceed the Saddle stitcher tray capacity. Touch [Folding] on the Basic Screen. The Folding Screen will be displayed. 6-20 bizhub 360...
  • Page 357 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 6-21...

  • Page 358: Output For Machine With Separator

    The output tray can be specified for each job type (Copy, Print, and Re- ports). See page 15-29 for details. To specify Separator output mode 0 As the default setting, Sort is selected. No limit is established in Sort mode. 6-22 bizhub 360...
  • Page 359 When using an alternating crisscross pattern, load 8-1/2 × 11- or 5- 1/2 × 8-1/2-size paper in crosswise orientation v into one paper tray and in the lengthwise orientation w into other tray. Touch [Finishing] on the Basic Screen. The Finishing Screen will be displayed. bizhub 360 6-23...
  • Page 360 Auto Paper Select may be released automatically depending on the setting you made. When using Sort or Group in alternating crisscross pattern, make sure that other copy conditions do not conflict with Auto Paper Se- lect. Press [Start]. The scan/print job will start. 6-24 bizhub 360...
  • Page 361 To cancel changes to the settings, touch [Cancel] on the Finishing Screen. To cancel all settings, press [Reset]. If no other setting is desired, the copy job can be started using the set- tings currently specified without touching [OK] to return to the Basic Screen. bizhub 360 6-25...

  • Page 362: Copy Conditions Incompatible With Finishing/Folding

    , , , , , , , , Group , , , , , , , , , Crisscross Offset Shifted Staple Punch Output Tray *8 *8 *8 , Fold & Staple *8 *8 *8 , Half Fold 6-26 bizhub 360...
  • Page 363 Half Fold or Fold & Staple in combination. *6: Varies according to the finishing option to be used. *7: Offset mode will be ignored. *8: Incompatible when Booklet is automatically selected with Half Fold or Fold & Staple in combination. bizhub 360 6-27...

  • Page 365: Advanced Information

    Advanced Information...

  • Page 366: Checking Feature Selections By Proof Copying

    Position the original, then set the print quantity. Select the desired copy conditions. Press [Proof Copy] on the control panel. A sample copy will be output, and the screen for checking the job set- tings will be displayed. bizhub 360...
  • Page 367 Make the setting change as desired. – The following settings can be changed from the screen after proof copying. Print Quantity Simplex/Duplex (except for the simplex/duplex original type) Finishing Folding Cover Mode Insert Sheet Chapters Page Margin Stamp/Overlay bizhub 360...
  • Page 368 Touch [Delete] to display the popup menu for confirmation, then touch [Yes]. Touch [Print] on the Proof Copy Screen. The machine will start printing the rest except the sample sets. bizhub 360...
  • Page 369 Advanced Information Detail To stop scanning/printing for the proof copy or to stop printing after proof copying, press [Stop] on the control panel. For details, see “To Stop/Resume/Delete a Job” on page 3-67. bizhub 360...

  • Page 370: Checking Feature Selections Before Copying (Mode Check)

    To use Mode Check function Position the original, and enter the desired print quantity. Select the desired copy conditions. – Scan the original, if any setting requires. Press [Mode Check] on the control panel. The Mode Check Screen will be displayed. bizhub 360...
  • Page 371 If setting change is desired, proceed to the next step. – If settings are OK, touch [Job End] on the Mode Check Screen, then proceed to step 7. Touch the key of the function to be changed. The setting screen for that function will be displayed. bizhub 360...
  • Page 372 To make more than one setting change, repeat the steps from 3 to Press [Start] on the control panel. The machine will start printing. Detail To stop printing, press [Stop] on the control panel. For details, see “To Stop/Resume/Delete a Job” on page 3-67. bizhub 360...

  • Page 373: Interrupt Copying

    When the machine is working on a printing job, the message “Job is stopping” will be displayed. The Interrupt LED lights up in green, and then printing job stops. Enter the print quantity for the interrupt job. Set copy conditions, as desired. bizhub 360...
  • Page 374 The interrupt copying will start. When the interrupt printing job is completed, press [Interrupt] again. The Interrupt LED goes off, and the settings of the initial job will be re- stored on the screen. The suspended printing will be continued automatically. 7-10 bizhub 360...

  • Page 375: Storing And Recalling Job Settings (Mode Memory)

    Position the original, then make the desired job settings. – Use control panel and touch panel keys to select the desired copy conditions. Press [Mode Memory] on the control panel. The Recall Copy Program Screen will be displayed. bizhub 360 7-11...
  • Page 376 Up to 16 characters can be entered. Use right/left arrow keys to move the cursor, and use [Shift] to enter upper case letters or symbols. Touch [OK] to return to the Basic Screen. The copy program has been stored successfully. 7-12 bizhub 360...

  • Page 377: To Recall Copy Program

    Mode Check Screen. For details, see “Checking Feature Selec- tions before Copying (Mode Check)” on page 7-6. Position the original. Press [Mode Memory] on the control panel. The Recall Copy Program Screen will be displayed. bizhub 360 7-13...
  • Page 378 The Check Job Screen comprises four different pages. The screen number for the current page is indicated in the center of the upper part of the screen. Touch [Back] or [Fwd.] to scroll to the desired page. 7-14 bizhub 360...
  • Page 379 Advanced Information – The functions which have been changed from the factory default appear highlighted on the screen. bizhub 360 7-15...
  • Page 380 To stop recalling the copy program, press [Reset] or [Mode Memory] on the control panel. The recalling procedure will be cancelled from any screen displayed on the touch panel. Otherwise, touch [Cancel] repeatedly until the Basic Screen is restored. 7-16 bizhub 360...

  • Page 381: To Change Program Name

    Press [Mode Memory] on the control panel. The Recall Copy Program Screen will be displayed. Touch the copy program key of the name to be edited, then touch [Edit Name]. The Program Name Screen will be displayed. bizhub 360 7-17...

  • Page 382: To Delete Copy Program

    0 The administrator can set the machine to lock the programs so that they cannot be deleted individually. In this case, the [Del.] key will disappear from the Recall Copy Program Screen to disable the procedure. For de- tails, see page 15-48. 7-18 bizhub 360...
  • Page 383 The Recall Copy Program Screen will be displayed. Touch to highlight the copy program key to be deleted. Touch [Del.]. The confirmation screen will be displayed. Touch [Yes]. The Recall Copy Program Screen will be restored with the selected copy program deleted. bizhub 360 7-19...

  • Page 384: Displaying Screen For Operation Guide (Help)

    Provides information on function and operation of the keys for scanner settings. - Fax Provides information on function and operation of the keys for fax set- tings. - Box Provides information on function and operation of the keys for box set- tings. 7-20 bizhub 360...

  • Page 385: Displaying Help Screen

    0 The information provided for Copy, Scan, Fax, Box, and Job List can also be displayed from each setting screen by pressing [Help] on the control panel. Display the Basic Screen, then press [Help] on the control panel. The Main Menu Screen will be displayed. bizhub 360 7-21...
  • Page 386 Touch the desired key to display specific information. – Touch [5 Functionality Map] to display the Function Map Screen to view a chart of available functions and settings on that topic. Use the control panel keypad to access the desired Help Screen. 7-22 bizhub 360...
  • Page 387 To view a detailed description, touch [Detail]. To jump to the screen in a higher level of the structure, touch the return arrow key. Touch [Exit] on the Help Screen, or press [Help] on the control panel. The Basic Screen will be restored. bizhub 360 7-23...

  • Page 388: Adjusting Control/Touch Panel Accessibility (Accessibility)

    - The [+] and [–] keys on the Zoom Screen. - The [Light] and [Dark] keys on the Density Screen. 7-24 bizhub 360...

  • Page 389: To Specify Key Repeat Start/Interval Time

    Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. Touch [1 Key Repeat Start/Interval Time], or press [1] on the control panel keypad. The Key Repeat Start/Interval Time Screen will be displayed. bizhub 360 7-25...
  • Page 390 The Basic Screen will be restored. Note Touch [Cancel] on the Key Repeat Start/Interval Time Screen to cancel the setting change. For details of the Enlarge Display mode, refer to the User’s Guide - En- large Display. 7-26 bizhub 360...

  • Page 391: Setting Timer For Enlarge Display Confirmation (Enlarge Display Timer Setting)

    If the popup menu is desired, select the period of time to display from 30, 60, 90, and 120 seconds. 0 Specified setting will be in effect only when the Enlarge Display mode is activated. Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. bizhub 360 7-27...
  • Page 392 The Enlarge Display Timer Setting Screen will be displayed. Touch [OFF], or the desired timer key to highlight it. – Select [OFF] for deactivate the Enlarge Display Confirmation popup menu. Touch [OK]. The Accessibility Setting Screen will be restored. 7-28 bizhub 360...

  • Page 393: Specifying Error Message Display Time (Message Display Time)

    To specify Message Display Time 0 The factory default is 3 seconds. Select either 3 seconds or 5 seconds for the display time. Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. bizhub 360 7-29...
  • Page 394 Select the desired display time. – Touch [3 sec.] or [5 sec.] to highlight it. Touch [OK]. The Accessibility Setting Screen will be restored. Touch [Close], or press [Accessibility] on the control panel. The Basic Screen will be restored. 7-30 bizhub 360...

  • Page 395: Enabling Key Tones (Sound Setting)

    0 Key Accept Sound/Key Refuse Sound, is enabled (ON) as factory default. 0 Warning Sound is enabled (ON) and Warning Sound Times is set to 3.0sec as factory default. Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. bizhub 360 7-31...
  • Page 396 Advanced Information Touch [4 Sound Setting], or press [4] on the control panel keypad. The Sound Setting Screen will be displayed. 7-32 bizhub 360...
  • Page 397 The Key Accept Sound/ Key Refuse Sound Screen will be dis- played. – Touch [ON] to activate, or [OFF] to deactivate. – Touch [OK] to return to the Sound Setting Screen. Select whether or not to enable warning sound. bizhub 360 7-33...
  • Page 398 The Warning Sound Screen Will be displayed. – Touch [ON] to activate, or [OFF] to deactivate. When selecting [ON], select one from [3 sec.], [5 sec.], or [10 sec]. – Touch [OK] to return to the Sound Setting Screen. 7-34 bizhub 360...

  • Page 399: Adjusting The Position Of Touch Sensor (Touch Panel Adjustment)

    If touch panel keys do not respond correctly, the touch sensor may shift in position of the touch keys. In this case, use this function to adjust the position of touch sensor. To specify Touch Panel Adjustment Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. bizhub 360 7-35...
  • Page 400 Touch the four check keys [+] to check the buzzer tone. When a check point is touched correctly, the Start LED on the control panel will light up in green. Is there a specific order to touch the check keys? % No. Touch them in any order. 7-36 bizhub 360...
  • Page 401 The position of the touch sensor will be adjusted, and the Accessibility Screen will be restored. Touch [Close], or press [Accessibility] on the control panel. The Basic Screen will be restored. Note Contact your service representative if adjustment result is not satisfacto- bizhub 360 7-37...

  • Page 402: Setting Auto Reset Notification (Auto Reset Notification)

    Auto Reset and System Auto Reset. 0 The factory default setting is “OFF”. Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. 7-38 bizhub 360...
  • Page 403 The Auto Reset Notification Screen will be displayed. Touch the key for the desired display time. – To not display the message requesting confirmation to reset the settings in Enlarge Display mode, touch [OFF]. – To cancel changes to the settings, touch [Cancel]. bizhub 360 7-39...
  • Page 404 Touch [OK] to return to Accessibility Screen. Touch [Close], or press [Accessibility] on the control panel. The Basic Screen will be restored. Note For details on the Enlarge Display mode, refer to the User’s Guide [En- large Display Operations]. 7-40 bizhub 360...

  • Page 405: Setting Enlarge Display Confirmation Screen (Enlarge Display Confirmation Screen)

    To specify Enlarge Display Confirmation Screen 0 The factory default setting is “No”. Press [Accessibility] on the control panel. The Accessibility Setting Screen will be displayed. bizhub 360 7-41...
  • Page 406 Select whether or not the message is displayed. – To cancel changes to the settings, touch [Cancel]. Touch [OK] to return to the Accessibility Setting Screen. Touch [Close], or press [Accessibility] on the control panel. The Basic Screen will be restored. 7-42 bizhub 360...
  • Page 407 For details on the Enlarge Display mode, refer to the User’s Guide [Enlarge Display Operations]. If [No] is touched in the message requesting confirmation to enter Enlarge Display mode, the screens are not changed. bizhub 360 7-43...

  • Page 409: Job Management (Job List)

    Job Management (Job List)

  • Page 410: Overview Of The Job List Screen

    “Job List” at the upper left corner of the screen. Types of the Job List Screen Besides copying, this machine provides computer printing, scanning, and user box features. There fore, the Job List Screens are classified into the fol- lowing three types: bizhub 360...
  • Page 411 For more details, refer to the User's Guide “Network Scanner Opera- tions”. - Job List Screen with the [RX/User Box] tab highlighted Displays data saved in boxes. For more details, refer to the User's Guide “Network Scanner Opera- tions”. bizhub 360...

  • Page 412: Tasks Available When The Job List Screen Is Displayed After Touching The [Print] Tab

    Switches to the Job History list which shows the list of jobs completed during the Current Jobs list is displayed. [Held Jobs] Displays and manages the list of jobs queued as a held job during the Job History list is displayed. bizhub 360...
  • Page 413 Time of Storage Displays the time that the job was queued. # of Pgs. Displays the number of pages in the original. # of Sets Displays the specified number of pages to be printed. bizhub 360...
  • Page 414 Cleared, Deleted by User, Mode cancelled from conflict) [Deleted Jobs] Displayes jobs deleted from the Job History list before printing was completed. [Finished Jobs] Displays jobs that were correctly completed in the Job History list. [Active Jobs] Displays all jobs in the Job History list. bizhub 360...

  • Page 415: Managing The Job List Screen

    Box functions. Touch [Job List] on the touch screen. – When the Current Jobs list using the Print functions is not displayed, touch the [Print] tab. The Current Jobs list using the Print functions will be displayed. bizhub 360...
  • Page 416 The specified Current Jobs list will be displayed. Detail The Current Jobs list displays active jobs when first displayed. To return to the screen displayed before touching [Job List], touch [Exit] or press [Reset] on the control panel. bizhub 360...

  • Page 417: To Display Job History

    When the Current Jobs list using the Print functions is not dis- played, touch the [Print] tab. The Current Jobs list using the Print functions will be displayed. Touch [Job History]. The Job History list using the Print functions will be displayed. bizhub 360...
  • Page 418 The list of jobs being selected is displayed. Detail The Job History list displays all the jobs when first displayed. To return to the screen displayed before touching [Job List], touch [Exit] or press [Reset] on the control panel. 8-10 bizhub 360...

  • Page 419: Check The Details Of Jobs In Current Jobs And Job History

    (Displayed only for Current Jobs transmitted to multiple recipients) Job History of the [Scan] tab - Result: Job complete, Error cleared, Deleted by User - Error Detail - Address - Type - User Name - Time of Storage - # of pgs. - File Name bizhub 360 8-11...

  • Page 420: Procedure

    When Job History is displayed, continue with step 4. Select the type of jobs to check details from Current Jobs. – To check the jobs that have been held, touch [Held Jobs]. The current list of jobs that have being selected will be displayed. 8-12 bizhub 360...
  • Page 421 Touch the desired job key, and then touch [Detail]. The Check Detail Screen will be displayed. What to do if an incorrect job key was selected? % Select a correct job key, or touch the key for the selected job again to deselect it. bizhub 360 8-13...

  • Page 422: Check The Settings Of Jobs Active Or Held In Current Jobs

    Select a job whose details are to be checked from the Current Jobs list. – To check the jobs that have been held, touch [Held Jobs]. The current list of jobs that have been selected will be displayed. 8-14 bizhub 360...
  • Page 423 Close the Check Job Details screen. – To return to Current Jobs, touch [Close]. – To return to the screen that was displayed before [Job List] was touched, touch [Exit], or press [Reset] from the control panel. bizhub 360 8-15...

  • Page 424: Delete Active And Held Jobs In Current Jobs

    What to do if an incorrect job key was selected? % Select a correct job key, or touch the key for the selected job again to deselect it. % A job can also be deleted after checking details of that job. See page 8-11. 8-16 bizhub 360...

  • Page 425: Increase Priority For Printing An Active Job In Current Jobs

    Touch [Job List] on the touch screen. – When the current list of jobs using the Print functions is not dis- played, touch [Print] tab. The current list of jobs using the Print functions is displayed. bizhub 360 8-17...
  • Page 426 % Select a correct job key, or touch the key for the selected job again to deselect it. How to stop printing the job given priority? % Touch [Cancel]. The Increase Priority Screen will be terminated and the current job list will be restored. 8-18 bizhub 360...

  • Page 427: Prints A Single Held Job In Current Jobs List And Checks Its Output Result

    The current list of jobs using the Print functions will be displayed. Touch [Held Jobs]. The current list of jobs being held will be displayed. Touch [Release Held Job]. The Release Held Job screen will be displayed. bizhub 360 8-19...
  • Page 428 % Press [Stop] on the control panel. Check the proof copy. The Current Jobs list will be restored. – To return to the screen that was displayed before [Job List] was touched, touch [Exit], or press [Reset] on the control panel. 8-20 bizhub 360...

  • Page 429: Change And Print The Settings Of Held Jobs In Current Jobs

    The current list of jobs using the Print functions will be displayed. Touch [Held Jobs]. The current list of jobs being held will be displayed. Touch [Release Held Job]. The Release Held Job Screen will be displayed. bizhub 360 8-21...
  • Page 430 To change the settings of the held job specified, continue with step 6. To leave the settings of the held job specified as is, continue with step Touch [Change Setting]. The Change Setting screen will be displayed. 8-22 bizhub 360...
  • Page 431 % Yes. Touch [Proof Print] on the Release Held Job Screen, and then touch [OK]. For more details, refer to the “1” on page 8-19. How to change the settings other than those displayed in the Change Setting Screen? % No. bizhub 360 8-23...
  • Page 432 How to stop printing? % Press [Stop] on the control panel. Close the Job List Screen. – To return to the screen that was displayed before [Job List] was touched, touch [Exit], or press [Reset] on the control panel. 8-24 bizhub 360...

  • Page 433: Paper And Original Information

    Paper and Original Information...

  • Page 434: Copy Paper

    - Saddle Stitcher SD-502 (for Finisher FS-510) - Mailbin Kit MT-501 (for Finisher FS-510) - Output tray OT-601 (for Finisher FS-510) - Output tray OT-501 (for the machine without finisher) - Job Separator JS-502 (for the machine without finisher) bizhub 360...

  • Page 435: Paper Weight

    “Offset” + “Sort” and “Offset” + “Group” settings: 13 to 35 lb Staple: 16 to 24 lb Punch: 16 to 24 lb Output tray OT-501 13 to 56 lb Job Separator JS-502 Tray 1 (Secondary tray): 13 to 56 lb Tray 2 (Primary tray): 15 to 24 lb bizhub 360...

  • Page 436: Paper Tray/ Output Tray Capacity

    8-1/2 × 14 or more: 1,500 sheets (20 lb) or 187.5 mm max. 8-1/2 × 11 or less: 3,000 sheets (20 lb) or 375 mm max. Output tray OT-501 100 sheets (16 to 24 lb) Job Separator JS-502 100 sheets (16 to 24 lb) bizhub 360...

  • Page 437: Paper Capacity In Finisher Fs-510 Output Trays

    Tray 3 output tray) “Sort” and “Group” settings 200 sheets 200 sheets 500/250 sheets “Offset ”+ “Sort” and “Offset” 200 sheets or 20 200 sheets or 20 500/250 sheets or + “Group” settings sets sets 50 sets/25 sets Staple bizhub 360...
  • Page 438 Finisher with Mailbin MT-501: 4 mail bins + 2 output trays Tray 1 Tray 2 Mail bins “Sort” and “Group” settings 200 sheets 500/250 sheets 500 sheets “Offset” + “Sort” and “Offset” 200 sheets or 20 500/250 sheets or + “Group” settings sets 50 sets/25 sets bizhub 360...
  • Page 439 “Sort” and “Group” settings 200 sheets 200 sheets 200/100 500 sheets sheets “Offset” + “Sort” and “Offset” 200 sheets or 200 sheets or 200/100 + “Group” settings 20 sets 20 sets sheets or 20 sets/10 sets bizhub 360...

  • Page 440: Paper Size

    Standard Size 2-hole: 8-1/2 × 14 w, 8-1/2 × 11 w Standard Size 3-hole: 11 × 17 w, 8-1/2 × 11 v 100 mm × 148 mm w to 314 mm × 457.2 mm w Exit tray OT-501 Job Separator JS-502 bizhub 360...

  • Page 441: Auto Tray Switch Function

    Setting”, if Auto paper select is functioned. Tray Priority is available. - Select “Allow” at “3 Auto Tray Switch ON/OFF” Load the following paper into the paper trays. - The same size in the same orientation. - The same paper type. bizhub 360...

  • Page 442: Special Paper

    Select this setting when overhead projection transparent films are loaded. Envelope Select this setting when envelope is loaded. Labels Select this setting when label sheets are loaded. Trace Paper Select this setting when trace paper is loaded. 9-10 bizhub 360...
  • Page 443 Colored Paper Select this setting when colored paper is loaded. Letterhead Select this setting when the paper that is loaded is already printed with a company name or preset text and, therefore, should be differentiated from Normal paper. bizhub 360 9-11...

  • Page 444: Precautions For Paper

    - Store the paper laying flat, not standing on its edge. Curled paper may cause paper misfeeds. - Keep paper out of the reach of children. 9-12 bizhub 360...

  • Page 445: Originals

    - Original that are bound together with glue - Original pages that have been cut or contain cutouts - Label sheets - Offset printing masters - Original with binder holes - Original that have just been printed with this machine bizhub 360 9-13...

  • Page 446: Positioning Original Into The Adf

    11 × 17 w, 8-1/2 × 14 w, 8-1/2 × 11 w/v, 5-1/2 × 8-1/2 v Width of 8-1/2 × 11 w/5-1/2 × 8-1/2 v: 8-1/2 × 11 w, 5-1/2 × 8-1/2 w/v Curling tolerance 10 mm or less Paper capacity 80 sheets (21-1/4 lb) or max. 11 mm 9-14 bizhub 360...

  • Page 447: Positioning Original On The Original Glass

    - Do not place objects exceeding 15 lb on the original glass, otherwise the original glass may be damaged. - If a book is placed on the original glass, do not press it down extremely hard, otherwise the original glass may be damaged. bizhub 360 9-15...

  • Page 449: Supplies & Handling

    Supplies & Handling...

  • Page 450: When The Message "Replenish Paper" Is Displayed

    - To load paper into a paper feed cabinet PC-402 (tray 3), see page 2-53. - To load paper into a large capacity unit LU-201, see page 2-56. - To load paper into the bypass tray, see page 2-58. 10-2 bizhub 360...

  • Page 451: Replacing Toner Cartridge

    “Replace the Toner.” is displayed. However, it is recommended that the toner cartridge be replaced when the message “Toner Cartridge needs to be replaced.” is displayed. When the toner is empty, the warning message shown below is displayed and copies can no longer be made. bizhub 360 10-3...

  • Page 452: Display In Enlarge Display Mode

    ] to display the message enlarged. 7 WARNING Precaution for the empty toner cartridge If it is thrown into a fire, the toner may ignite and cause a dangerous situation. DO NOT THROW toner or the empty toner cartridge into a fire! 10-4 bizhub 360...

  • Page 453: To Replace The Toner Cartridge

    Otherwise, machine trouble may occur. Open the machine front door, then open the toner cartridge door. – When opening the toner cartridge cov- er, release the lock of the cover. bizhub 360 10-5...
  • Page 454 – The toner within the toner cartridge may 5~6cm have become com- pacted. Be sure to handle steps 4 to 6 until the toner is mostly broken up be- fore installing the cartridge. 10-6 bizhub 360...
  • Page 455 Loosen toner by tapping top of the new toner cartridge on a solid sur- face at least five times. 5~6cm Shake the new toner cartridge by turning it over about five times. Remove the cap from the new toner cartridge. bizhub 360 10-7...
  • Page 456 Return the cartridge holder to its original position Close and lock the toner cartridge cover, then close the machine front door. 10-8 bizhub 360...

  • Page 457: Adding Staples

    When either of the two staple cartridges becomes empty in the Saddle stitcher SD-502 mounted on Finisher FS-510, the Basic Screen displays the following message in the message area. For details on replacing the staple cartridge for Saddle stitcher SD-502, see page 10-18. bizhub 360 10-9...

  • Page 458: Display In Enlarge Display Mode

    0 Be sure to replace the staple cartridge after displaying the message, oth- erwise the machine may be damaged. Slide the finisher to the left. – Holding the finisher handle on the top, slide the finisher to the left until it stops. 10-10 bizhub 360...
  • Page 459 Turn the dial to the left until the two staplers come to the center. Pull up then forward the staple holder to remove it from the stapler. – Please check the message which sta- pler to remove. Staple cartridge 1: rear side Staple cartridge 2: front side bizhub 360 10-11...
  • Page 460 Install the new staple cartridge into the staple cartridge. – Push the staple car- tridge, and then check that the car- tridge is securely in- stalled. Push down the top cover to return it to its original position. 10-12 bizhub 360...
  • Page 461 Supplies & Handling Remove the lock tape from the cartridge. Return the staple holder to the stapler, and push it down until it clicks in place. Close the finisher right door FN7. bizhub 360 10-13...

  • Page 462: To Replace The Staple Cartridge For Finisher Fs-510

    If necessary, turn the stapler moving knob to bring the stapler forward. Touch [Finishing] on the Basic Screen. The Finishing Screen will be displayed. The [Add Staples] key will ap- pear on the Finishing Screen. 10-14 bizhub 360...
  • Page 463 When moving toward completely, the Check Stapler Screen will be dis- played. When the Check Stapler Screen is displayed, open the finisher front door. – Moving Stapler Screen DO NOT open the finisher door while the Moving Stapler Screen is displayed. – Check Stapler Screen bizhub 360 10-15...
  • Page 464 “PUSH” buttons of the staple holder to slide the top cover upward, then remove the empty staple car- tridge. Install the new staple cartridge into the staple cartridge. – Firmly insert the new cartridge into staple holder. 10-16 bizhub 360...
  • Page 465 Supplies & Handling Push down the top cover to return it to its original position. Remove the lock tape from the cartridge. Return the staple holder to the stapler, and push it down until it clicks in place. bizhub 360 10-17...

  • Page 466: To Replace The Staple Cartridge For Saddle Stitcher Sd-502

    1 just un- der the saddle stitch- er tray is withdrawn, push it back to its original position, oth- erwise it may disturb you in the following procedure or ma- chine trouble may occur. 10-18 bizhub 360...
  • Page 467 “PUSH” buttons of the staple holder to slide the top cover upward, then remove the empty saddle staple cartridge. Install the new saddle staple cartridge into the staple cartridge. – Firmly insert the new cartridge into staple holder. bizhub 360 10-19...
  • Page 468 Supplies & Handling Push down the top cover to return it to its original position. Remove the lock tape from the cartridge. Return the staple holder to the stapler. – Hold the staple hold- er as shown right. 10-20 bizhub 360...
  • Page 469 Open the stapling part of the saddle stitcher, then close it. The saddle stitcher will be reset, and the copying job using Fold & Sta- ple mode will be available. bizhub 360 10-21...

  • Page 470: Emptying Dust Boxes

    0 The punch dust box is not disposable. Be sure to return it to its original position. Slide the finisher to the left. – Holding the finisher handle on the top, slide the finisher to the left until it stops. 10-22 bizhub 360...
  • Page 471 Supplies & Handling Open the finisher right door FN7. Pull out the punch dust box. Empty the punch dust box. bizhub 360 10-23...
  • Page 472 Return the punch dust box, then close the finisher right door [FN7]. Slide the finisher to the right to return it to its original position. To empty the dust box of PU-501 Open the finisher front door. 10-24 bizhub 360...
  • Page 473 Supplies & Handling Pull out the punch dust box. Empty the punch dust box. Return the punch dust box, then close the finisher front door. – Firmly reinstall the punch dust box. bizhub 360 10-25...

  • Page 475: Troubleshooting

    Troubleshooting...

  • Page 476: When The Message "Malfunction Detected" Appears (Call Technical Representative)

    Call Technical Representative Screen. When the screen is displayed, be sure to contact your technical representa- tive immediately by following the procedure below. Display in Enlarge Display Mode If a malfunction occurs, the screen shown below is displayed. 11-2 bizhub 360...

  • Page 477: To Call The Technical Representative

    Troubleshooting Touch [ ] to display the message shown in the following illustration. To call the technical representative Write down the malfunction code (for example, C-0001) in the Call Technical Representative Screen. bizhub 360 11-3...
  • Page 478 After the message “Malfunction was detected. CS Remote Care has called the Service Center.” is displayed, turn off the sub power switch and the main power switch, and then unplug the machine from the elec- trical outlet. 11-4 bizhub 360...

  • Page 479: When The Message "Misfeed Detected" Is Displayed

    Jam number indicates the location of the paper misfeed, and area the arrow indicates the operation for clearing the misfeed. Reminder Before clearing paper misfeeds, be sure to check pages 1-13 to 1-14 for the locations of caution labels. bizhub 360 11-5...

  • Page 480: To Clear A Paper Misfeed

    If the description of the illustration extends over multiple pages, [Next %] is displayed on the lower-right corner of the screen. Touch [Next %] to display the next screen. – To return to the previous illustration description screen, touch Back]. 11-6 bizhub 360...
  • Page 481 Precaution for high temperature Parts around the rail for stapler of the Finisher FS-510 are extremely hot. In order to reduce the risk of burns, do not touch any part in this unit when clearing paper misfeeds. bizhub 360 11-7...

  • Page 482: When The Message

    Copy mode. Display in Enlarge Display Mode Continue the operation according to the following instructions. - To print all pages that have been scanned, touch [Print]. - To delete the job for the scanned pages, touch [Delete]. 11-8 bizhub 360...

  • Page 483: Memory Becomes Full While Queuing A Job

    Display in Enlarge Display Mode Check the number of pages counted for the document, and then adjust the number of pages in the job to be queued. bizhub 360 11-9...

  • Page 484: Simple Troubleshooting

    Wipe the document pad with a dirty? soft, dry cloth. (page 12-3) Was the original docu- Place a blank sheet of paper on ment printed on highly top of the document. translucent material, such as trace paper or overhead projector transparencies? 11-10 bizhub 360...
  • Page 485 (with a re- ed paper size. Otherwise, select duced zoom ratio the “Auto Zoom” setting to re- specified)? duce the copy to the selected paper size. (page 3-43) bizhub 360 11-11...
  • Page 486 FS-510) If any message other than those listed above is displayed, perform the oper- ation described in the message.If the problem is not corrected after the de- scribed operation is performed, contact your service representative. 11-12 bizhub 360...

  • Page 487: Main Messages And Their Remedies

    Since the toner has run out, Replace the toner cartridge. the machine is unable to make copies. Stapler empty. Replace Staple The staples have run out. Replace the staple cartridge. Cartridge or cancel Staple (page 10-9) mode. bizhub 360 11-13...
  • Page 488 If any message other than those listed above is displayed, perform the oper- ation described in the message. If the problem is not corrected after the de- scribed operation is performed, contact your service representative. 11-14 bizhub 360...

  • Page 489: Machine Maintenance

    Machine Maintenance...

  • Page 490: Cleaning

    Raise the ADF, and clean the surface of the original glass by wiping it with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the original glass. 12-2 bizhub 360...

  • Page 491: Cleaning The Document Pad

    Clean the paper take-up roll- ers by wiping them with a soft, dry cloth. Reminder Never use solvents, such as benzene or thinner, to clean the paper take- up roller. bizhub 360 12-3...

  • Page 492: Cleaning The Writing Unit Glass And The Electrode Wires

    Reminder Be sure to turn off the main power switch before cleaning it. Never use solvents, such as benzene or thinner, to clean the main unit. 12-4 bizhub 360...

  • Page 493: Cleaning The Control Panel

    Reminder Pressing too hard on the control panel or the touch panel may damage them. Never use a mild household detergent, glass cleaner, benzin or thinner to clean the control panel or touch panel. bizhub 360 12-5...

  • Page 494: Viewing Counters (Meter Count)

    The detailed counter can be verified to touch [Details] in the sub display area. The list of counters can be printed. To check and print the counter list Press [Utility/Counter] on the control panel. The Utility/Counter Screen will be displayed. Check the list. 12-6 bizhub 360...
  • Page 495 Machine Maintenance Touch [Details] in the sub display area. bizhub 360 12-7...
  • Page 496 [Start] on the control panel. Touch [Close] on the Utility/Counter Screen. The Basic Screen will be restored. Note The list of counters can be displayed even while the copying or printing operation is in progress. 12-8 bizhub 360...

  • Page 497: When The Message "Preventive Maintenance Time" Is Displayed

    After a set number of copies (225,000 copies) have been made on your ma- chine, Preventive maintenance will be required for maintaining optimal per- formance. If the message “Preventive maintenance time.” is displayed, contact your technical representative and request a periodic maintenance inspection. bizhub 360 12-9...
