Component Identification

Component Component
Figure 1 Components of the Air-Assisted Isolation System in a Typical Waterborne Manual Batch System
Key
Key Key
Item Description
Item Item Description Description
A Air Inlet
C Control Interface
CC Color Change Module (on color change
enabled systems)
D
Air Outlet to Gun
E Fluid Outlet to Gun
F Fluid Inlet
Isolation Valve
G
J Fluid Inlet Valve
K Isolation Fluid Pump
3A7370C
Identification
Identification
Component Identification
Item Description
Item Item Description Description
L Merkur AA Fluid Pump
M Electronics Panel
N Ground Rod and Bleed Resistor
P Power Supply
R Hand-held Grounded Rod
VS Color Change Valve Stack (on color
change enabled systems)
W Wash Fluid Bottle
Z Fluid Filter (100 mesh)
