3 Enter or select the .cfm file you are saving to and click OK.
4 When the save is completed, click OK.
Restoring a
Configuration from
CFM
1 From the IP Telephony Manager Console window, select File menu, and click
Figure 21 Save Chassis CFM Dialog Box
The default directory for .nvr files is: $TCMHOME/data/nvram/.
If you are saving or restoring from the command line and you are not using the
x prefix option, progress is reported as status messages on screen. For more
information refer, to Appendix B, Command Line Interface.
The Chassis Save Progress window appears.
Use the following procedure to restore the configuration of the Media
Gateway chassis, Gatekeeper, SIP Proxy Server, or Back-end Server to the
Configuration File Manager (CFM) using the IP Telephony Manager.
Restore CFM.
The Restore CFM dialog box appears.
Saving and Restoring Configurations
47
