Auto Response
AutoResponse
Configuration
AutoResponse lets network managers define a set of actions (auto response
script) to be taken automatically when a specified event occurs in the chassis.
The event may be specific to a particular module (NAC or NMC) in a given slot
of the chassis, or specific to a particular entity (such as a single modem
channel).
IP Telephony Manager provides a convenient graphical user interface (GUI) for
the Network Manager to configure automatic responses to a specified event. It
is available on the AutoResponse drop-down menu from the Configure menu.
IP Telephony Manager does not need to be running when an event occurs for
the NMC to invoke the appropriate response, because these responses are
programmed into the NMC.
When there are thresholds for an event, they must be programmed through
the Configuration Tool. For example, the Connection Time Limit Expired event
requires that you specify the Connection Time Limit threshold.
To define the automatic responses:
1 Click one or a group of slot(s)/channel(s) on the IP Telephony Manager console
window.
2 On the Main Menu bar, click Configuration, and then click AutoResponse.
If you selected the edge server card, click OK on the Select Entity window.
The AutoResponse window appears.
If you selected the HiPer DSP card, select where you want the auto response
to be set, either the card or template level and click OK.
The AutoResponse window appears.
Figure 4 AutoResponse Window
Auto Response
31
