Control Systems
3
Integrated management system
3
3-2. S-NET3 (MST-P3P)
❷
Schedule modification
•
Click the set schedule display window twice to display the modification panel.
Then it is possible to modify various functions such as schedule time, operation mode and
temperature setting.
•
Able to carry out various functions such as a schedule name change, schedule delete, indoor unit
addition and deletion with the icons on the left menu window.
Modify a schedule name.
Usage time and power consumption
➊
Usage time and power
•
Able to search for the power consumption and usage time by different conditions including the total
indoor units applied to S-NET3, Centralized controller, individual indoor unit.
Total indoor unit usage reference
❷
Power consumption report
•
Able to print out the amount of power consumed for a specific period of time in the form of report.
•
The applicable formats include PDF, TXT, HTML, CSV, MHT, EXCEL, graphic documents.
V-122
3/6/08 14:04
Page 122
Add/ Delete indoor unit for schedule
control.
Delete a set schedule.
Individual indoor unit usage reference
Types of document to be stored
